FROM the pages of the February 1934 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Guns and Howitzers

by Robert Sidney Bowen (Sky Fighters, February 1934)

BY THIS time, you yeggs—excuse me, my error. I’ll start all over again. By this time, you buzzards must be convinced that we war pilots were very wonderful fellows.

Of course, being a modest old sparrow I can do nothing else but agree with you. However, to be serious for a few moments, the object of this little get-together is to point out that the pilot who was sent to the Front during the last war had to know quite a bit about war activities other than just the flying end.

When you enlisted there was really no way of determining whether you would be okay on pursuit ships, observation ships, or bombers. That being the case, the training you received was more general than specialized.

By that I mean, you were taught at ground school the various duties of all three types of pilots. And upon your flying depended what kind of a squadron you’d be sent to—if any!

For instance, it might so happen that once you had been sent solo you proved yourself to be a knockout on artillery co-operation work. In that case you’d be shipped to an observation squadron. And then again, perhaps, you might be a dead shot. In that case, out you’d go to a pursuit unit.

Get the Idea?

Why waste a swell shot by sticking him at the controls of a bomber? Get the idea?

Naturally, war being just as mixed up as anything else, the right men were not sent to the right squadrons all the time. There were plenty of misfits floating around—birds pushing bombers around when they should be at the controls of a pursuit or an observation ship, and vice versa. However, that sort of stuff was not the fault of the pilot in question.

Just One of Those Things

It was just one of the many, many things that can happen in war. In other words, you were sent where the big shots sent you, and that was that. You couldn’t do anything about it, except weep in your own soup.

I remember a case in particular. There were two friends of mine, one a big bruiser and the other a little half pint portion of man—but plenty scrappy, nevertheless. Well, we all trained together, and when it came time for us to be assigned to squadrons, the big fellow was sent out to a Camel squadron and the little fellow was shipped out to fly Handley-Page bombers.

The funny part of it was that I met them both about six months later, and the big fellow had to have his Camel cockpit made bigger so he could get into it, and the little fellow had to pile leather cushions in his Handley-Page cockpit in order to see over the top of the cowling.

They both came through the war with flying colors, so maybe the big shots guessed right after all.

However, whether they did or not, isn’t any skin off our noses today. What I’m trying to get over to you chipmunks is, that while you were training for the Front you were learning lots of things about war besides flying. In other words, you had to be able to fill any gap at a moment’s notice.

And so, I’m going to yell about one of the extra items we had to get through our heads before they let us go. And that item is ordnance.

Or—what? You heard me, ordnance! And being as how you don’t know what that means, I suppose I’ll have to tell you. The correct definition of ordnance is, the general name for all kinds of weapons and their appliances used in war; especially, artillery.

What’s a Gun—Huh?

That last is what I’m going to talk about—artillery.

There were, generally speaking, three types of artillery used. The first was guns, the second was howitzers, and the third was mortars.

Now wait a minute, keep your shirt on and stop asking questions so soon. I know what’s on your mind. What do I mean by guns? Well, just listen.

A gun was a piece of ordnance, cannon or pieces of artillery that was used foe, long-range fire, or in other words, line fire. A howitzer was a piece of ordnance, cannon or pieces of artillery used for short range destructive fire. And a mortar was a piece of ordnance, cannon or artillery that was used for short range, very high angle of fire bombardment work.

The Long and the Short of It

Now, let’s go into detail one at a time. First, the gun.

Of course, there were various sizes of guns. The smallest being the eighteen-pounder and the largest being the twelve-inch gun. And even bigger than that if you want to count the navel guns they sometimes mounted on mobile platforms. However, regardless of the size of the gun, the bores were all rifled to give the desired twist to the shell as it left the muzzle, so that it would travel through the air the right way.

Naturally, the driving band that circled the shell made it possible for the rifling of the bore of the gun to give a twist to the shell.

As I said, guns were used for long range work or line fire. By line fire I mean just that—the shells exploding in a line area that extended from a point on the near side of the target to a point on the far side of the target. In other words, an oblong target area. To get an exact idea of what I mean, take a squint at Fig. 1.

As the shell of a gun has to travel a long way, it follows that the muzzle velocity (speed of shell as it leaves muzzle of gun) is very high. However, on the other hand, the trajectory and angle of descent are very low. To explain them there big words: trajectory means angle of flight. And angle of descent, of course, means the angle in relation to the ground at which the shell descends.

Effective Range Fire

Guns were more effective on infantry movements. By that I mean, infantry columns moving along roads, field batteries moving into position, trains, railroad stations, ammo dumps, etc. In other words, targets that were either moving or stationary, but were quite a ways behind the enemy lines. See Fig. 2.

Now, I’ll get on with howitzers and you’ll be able to see just what I mean about the effective range fire of guns.

Howitzers ranged in size from four and a half inches to around sixteen inches.

Howitzers Were Accurate!

And, by the way, when I speak of size I mean the diameter of the bore of the gun or howitzer, such as the case may be.

Okay, let’s go! Howitzers were used for short-range destructive work. By that I mean, they were supposed to wipe the target right off the old map. Their range being shorter, they were far more accurate than guns. The main reason being that their area of fire was more square in shape than the area of gun-fire.

To get the point, rest your lamps on Fig. 3.

The range of howitzers being shorter the idea was to drop a shell down on it as perpendicular as possible. To do this, required low muzzle velocity, high trajectory and high angle of descent. The advantage of howitzers was that hills didn’t bother them. Their shells went up high and came down at a steep angle. So if your target was behind a hill range, you didn’t have to worry.

A gun shell that would clear the top of the hill would, of course, go beyond the target. But a howitzer shell would sneak right up over the hill and plop straight down, on the target. Take a peep at Fig. 4 and you get an idea how a howitzer shell went through the air.

Now, when I say that howitzers were for destructive work, don’t get the idea that guns didn’t destroy things. They sure did, and don’t let your cousin Alice tell you otherwise. However, perhaps you noted that howitzers pushed out bigger shells than guns, and that those shells came down straighter on the target.

Well, there you are—howitzer fire was more evenly concentrated than gun-fire, it covered a more even area about the target, and it could nail a target (within its range) regardless of ground formations. Because of its high trajectory and short range it was the bunk for moving targets.
But take an established enemy target, a field battery in position, for instance, or a troop concentration depot, and the old howitzer would give you the best results every time.

The Howitzer’s Kid Brother

A mortar was for trench to trench work. The most famous of all mortars was the Stokes trench mortar. It popped one- or two-pound shells out of your trench and down into the enemy trench. As its range of fire was nothing to write home about, a couple of hundred yards or so, the bore was not rifled, nor was there any driving band on the shell. I suppose that you could really call a trench mortar, a small edition of a howitzer without bore rifling.

Believe it or not, they were fired by dropping the shell into the muzzle. It simply slid down, detonated and came popping out again and on its way over to the enemy trench. Yes, Clarence, you had to get your hand out of the way fast. That is, of course, if you didn’t want to present the enemy with a perfectly good hand. Personally, I never met a soldier yet who didn’t want to hang onto his hands.

And there you have a general idea of artillery used in the last mix-up. Don’t forget there were all kinds of guns and all kinds of howitzers and each kind had a special use in defensive or offensive work.

However, a gun was just as different from a howitzer as a revolver is from a rifle. But both were hot stuff for their own particular type of work.

And now, just a couple of words about artillery work in general and its relation to aircraft. The work can be tabulated as follows—registration on the target for future bombardment, the bombardment itself, wire cutting and trench destruction before an infantry attack, barrage fire during an attack and emergency target work. Registration on a target (range finding) and bombardment of target work were carried out in co-operation with aircraft.

The other classes of work were carried out in co-operation with ground observation or on the initiative of the officer commanding the battery. But no matter what type of work it was, the thing that counted with G.H.Q. was results. And, now that I think of it, the only thing that ever counted with G.H.Q. was results. Nix on explanations—you had to give those big pumpkins results if you wanted to stay out of hot water.

And so there you have one non-flying item that we pilots had to learn by heart. Maybe, if you are all good little children, I’ll tell you about something else that we had to absorb before they let us become Fokker fodder. Goombye!

FROM the pages of the January 1934 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Night Flying

by Robert Sidney Bowen (Sky Fighters, January 1934)

WELL, I note that both of you sparrows are here again. And I suppose that means I’ve got to do some talking and improve your knowledge as to the activities of myself, and other world renowned heroes, during the late unpleasantness.

This time I’ll gabfest on the advantages, disadvantages, and ups and downs of night flying in the days when girls used to marry uniforms.

A Mean Job

To begin with, let me say that next to daylight bomb raids, night flying was about the meanest and toughest job that the C.O. could pass out to you. You seldom saw what you were banging away at, and the other guy wasn’t any better off.

How-the-some-ever, night flying was not originated with the idea of giving pursuit pilots something else to do. As a matter of fact, pursuit ships didn’t begin to take much part in night flying work until along about the last year of the war.

Generally speaking, night flying, simply meant bombing raids at night. Long range assignments with destinations far behind the enemy lines.

The Germans Started It

To get at the idea from a historical viewpoint, night flying in the world war was really first started by the Germans. How, you ask? With their Zeppelins, stupid. Why certainly! The Zeppelin raids on London and Paris were made under cover of darkness.

The reason for that is, of course, quite obvious. A Zeppelin raid in the daytime would be just too bad for the Zeppelin. It would be spotted long before it reached its objective.

No, Alice, this is not going to be a discourse on Zeppelin raids. So tuck in your bib and pay attention.

I spoke of Zeppelins being first used in night flying work to point out the fact that night flying was fundamentally an offensive maneuver.

How come?

Home Defense Squadrons

VERY well, let me explain the difference. In the daylight your air force raids enemy territory, repels enemy raids into your territory, and also reconnoiters enemy territory. In short there is a definite object for every patrol. But at night there were no scheduled patrols for planes on the receiving end. And by the receiving end, I mean territory that was being raided. To make it a bit more clear than that, flights of ships whose job it was to repel night invaders or raiders, didn’t take to the air until the raiders made the first move. Such squadrons were known as Home Defense Squadrons. And that’s just what they did—defended the fireside against invaders. In other words, in the daytime you flew patrols whether the enemy was there or not. But at night you only flew when the enemy came to call.

Rather than frighten the French and English populace, Zeppelin warfare made them all the more determined to defeat Germany.

Not favoring the construction of Zeppelins, or I should say, lighter-than-air-aircraft, the Allies started to hit back with long range bombing raids (Fig. 1) on German strongholds behind the lines. Most of these raids were conducted by the English, and to them should go everlasting praise for their accomplishments.

Not tor the Chicken-Hearted

A bomb raid at night is not a job for chicken-hearted men. To begin with, you’ve got to have a clear night to see things on the ground. Nowadays with blind flying developed as it is, with airway beacons, and all the rest of it, a pilot can fly from here to there and back again in almost any old kind of weather. But in war days a clear night was very essential.

But as even you two nitwits can see, what was a break for the raiders was also a break for the defenders. In other words, if you could see them, they could also see you.

There were no special hours of the night for bomb raids. The time of take-off really depended upon how far you had to fly before you could let the old “eggs” go whanging down. But the dangers of night bombing raids began just as soon as you opened up the throttle.

Today when a ship takes off at night, the runway is bathed in flood lights, and it’s just about as easy as a daytime take-off. But in war days, you did the best you could and trusted to luck for the rest. There were no flood lights, or any of the other fancy gadgets that you have today. The “runway” was simply the best part of your drome, and it was lighted by parallel rows of oil pots (Fig. 2). The ship simply took off between the two rows.

What They Looked Like

And speaking of oil pots, next time you’re out driving with the girl friend at night (you do, don’t you?) and you come to a spot where they’re digging up the road, take a look at those ball-like things that rim the ditch. They look like a bomb full of oil, and burning at the top. Well, those things are what oil pot flares used to look like during the war.

WELL, as soon as you’ve taken off, the oil pots are doused, because it’s not any help to advertise the location of your drome to any enemy ships that might be upstairs. And after those oil pots go out, the rest is up to you. If there is more than one ship in the raid, each pilot has got to make sure he doesn’t ram into the other guy. To avoid that they usually flew in follow-the-leader-style. Not only did that permit the pilot to see the exhaust flames of the ship ahead, and thus keep his distance, but it also permitted more effective bombing of the objective. When the objective was reached the first plane would drop its bombs and then bank wide and swing for home. The second ship would do the same thing, and after it, the third ship, and so on.

Naturally, while you are heading for your objective the enemy hears you, and he tries to spot you with his searchlights. And when he does, look out, because you’re going to get a shower bath of archie in the next few seconds. When one searchlight gets you, two or three others swing right over with the idea of “boxing” you—fixing you so’s you can’t dodge either way into the darkness, and escape. At such times, good piloting counts plenty, and how.

Of course, most of the time defending ships don’t wait for searchlights to nail you. They come streaking up, using your exhaust flames as a guide to where you are. And in turn your gunners use their exhaust flames as a guide to where the attacking pursuits are.

The Return Trip

Once you’ve let your eggs go, you can bet your shirt that the enemy is going to try his damnedest to get you. And so the return trip is really worse than the journey out. Besides, you’ve got to get the ship down okay.

When the home drome mechanics hear you, they set out landing marks on the drome. These are oil pots set out in a way that will indicate the direction of the ground wind. There were two signs generally used. One was in the shape of a big L, (Fig. 3) the bottom of the L being at the leeward side of the drome. In other words, you landed along the upright part of the L, toward the bottom piece. The idea being that the area formed by the angle was the smoothest part of the field.’
The other sign were lights in the form of a T, (Fig. 4) with the crosspiece being toward the leeward side of the field. And so you simply landed along either side of the leg of the T, toward the cross piece.

Sounds simple, doesn’t it? Well don’t kid yourself, sweetheart. Those oil pots never did blind you with their light, and it took wonderful pilots (like me) to get down without jarring the other guy’s teeth.

Night Pursuit Flying

To get the idea of pursuit flying at night, just reverse what I’ve been telling you about a night bombing raid. The night pursuit ships (or, bats, as your favorite authors like to call them) simply took the air when enemy bombers were announced. Their job consisted of two things. One, to get the bombers.

And the other, to avoid smacking into one of their own men. I never could decide just which job gave me the most gray hair.

Just one more thing, and I’m gone. It’s about sighting landmarks at night. One tough job, children, unless there’s a moon. About the only thing you can really see clearly, is water—rivers, lakes, etc. The rest you guess at. And here’s an interesting item lots of folks don’t know. It was a cinch for German Zeppelins to find either London or Paris at night. Why? Because both cities are on a river, and their metropolitan areas are exactly between two islands in each river, both the Thames and the Seine. They simply hovered over either of those areas and let go. And speaking of “go,” that means me. too! Good evening.

FROM the pages of the December 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Flying Comfort

by Robert Sidney Bowen (Sky Fighters, December 1933)

SO! SOUND asleep, the lot of you, eh? Well, my pin-feathered buzzards, that suits me just fine. In fact, it’s perfect. It gives me an idea of what to chin about this time. For a week I’ve been lying awake nights, tearing out my hair, wondering what I could talk about that would be close to your dear little hearts, and which you’d all understand.

Well, you yourselves gave me the idea. What subject could you better understand than one dealing with comfort?

And so, I will proceed to raise my usually calm and soothing voice above the stentorian chorus of snores, and bellow at you about the art of flying comfort.

We Were Comfortable

Though it breaks my heart to reveal the truth, my conscience forces me to draw aside the veil and show just how comfortable we baldheaded eagles were in the days when the word German was something that made you jump and jump fast.

As your big sisters have probably told you, wartime airdromes were never located in the middle of No-Man’s-Land. In fact, they were usually fifteen to twenty miles behind the lines. Such being the case, we had no fears of waking up and finding German infantrymen plowing through the room. And so, we could add the old home sweet home touch to our abodes and know that it would all still be there when we got back from a gallant patrol.

Sure! We had hutments to live in, blankets and clean sheets. A mess lounge to get plastered in, too. True, the furniture was not all mahogany or birdseye maple. However, it didn’t fall apart, much. And most important of all, my dears, the grub was good. It wasn’t dropped in the mud, and it was cooked (by a cook) in a real stove. There was usually some sort of a piano that worked. And, of course, the ever-present phonograph.

Now, before I mislead you too much, let me explain that the pilots more or less enjoyed solid comfort only as compared to the men holding the line.

I COULD name lots of places that are heaven compared to a wartime airdrome, and not even exaggerate. So, just keep it in your think-box that I’m speaking of flying comfort as compared to infantry or artillery comfort.

Visiting the Neighbors

And so, we were able to install all the little things that helped to make life enjoyable when not in the air. Usually there was a village near-by, with at least one worthwhile estaminet where we could go between patrols or any time when we were off duty. Also, if the field was big enough, more than one squadron used it, with the result that you had neighbors to visit, etc.

IN OTHER words, while an airman was on the ground, it really was a pretty good war.

In the air, though, it was different. And naturally so, because for us, that’s where the war was—in the air.

But here’s the point—we didn’t confine all our efforts for comfort to the time when we were on the ground. We took it along with us when we went up, providing, of course, it didn’t interfere with air scrapping.

That, of course, was the one essential thing to think about. And as a result, the comfort that we tried to get in the air was in reality a type of comfort that actually helped air performance.

Just a Few Examples

For a few examples of what I mean, unbutton your ears to these.

Straight flying—ordinary patroling between two points—is about the most monotonous thing east or west of the Seven Seas. There’s nothing to do but sit and fly, and then sit and fly some more. On a smooth day your legs and arms and neck get so doggone cramped, that you suddenly’ find yourself praying aloud for a flight of enemy ships to drop down on you.

True, you’ve got to keep your eyes open, to spot said enemy ships ahead of time.

And also you’ve got to keep on the alert so that you won’t slide out of formation position. But after awhile at the Front that sort of thing becomes almost mechanical. Like a sixth sense, you might say.

To permit themselves the opportunity to relax, some of the boys had headrests fitted to the top of the fuselage just back of the cockpit. The headrest was just a leather pad streamlined into the top of the fuselage. On some ships, the S.E.5, for example, the headrest was already there. And to show you how queer war pilots can be, some of the guys had the headrest of their S.E.5
taken off, because they said it cramped their necks! (See Fig. A.)

Every Little Thing Counts

ANOTHER little thing that we added for comfort’s sake, was a little box fitted to a fuselage crossbrace inside the cockpit. In ships that had a Lewis gun mounted on the top center section, the box was already there. That is, there were two boxes in which you carried a couple of spare Lewis drums of ammo. So you simply carried one extra drum—and the other was your box.

What for? Why, to keep things in, dummy. What things? Well—that depended upon the pilot’s likes and dislikes. Me, I used to slip a couple of bars of chocolate in, a cloth with which to wipe oil spatterings off my goggles, a couple of nips of this and that in a flask (in case of a cold, you understand), a picture of the current girl friend to gaze at if I felt lonely, a box of matches, and at least one deck of cigarettes.

Cigarettes?

Ah, I knew darn well that buzzard over there in the corner wasn’t asleep! Sure, we carried cigarettes. Why not? No, not to smoke while we were in the air. Nix! Can do, as a stunt. But didn’t as a regular practice.

No, the idea was, in case we got forced down and taken prisoner. Yes, sir, we were that way. Made sure of our comfort—in case. And if you think that’s a funny idea, go get yourself taken prisoner some day, and find out how many smokes the enemy gives you! Yeah, you’!I learn!

If We Were Captured

AND speaking of being taken prisoner. Some of the lads used to sew a small compass and a map or two in the lining of their flying suits. I once heard of a case where that little stunt was the means of a bird escaping an enemy prison camp. Well, all I can say is, that guy sure was lucky, and then some!

In the first place, the enemy wasn’t as dumb as the newspapers try to make them out to be. They knew a few things about fighting a war just as we did.

And searching a captured prisoner for anything that might help or hinder him was something that the Germans did nothing else but. However, for argument’s sake, let’s say that the searching officer was blind in one eye, couldn’t see out of the other, and both hands were cut off. Well, the hero goes to a prison camp, tells the guard to look the other way, and sets off for home. He uses the compass and starts south. Soon it gets darn cold and he meets an Eskimo. Heavens, he’s been walking all these weeks in the opposite direction.

And why? Because that little compass sewed in his flying suit was long ago sent haywire by the metal and ignition system of his engine.

But to get back to that box—comfort box, you could call it—I’ve told you a few of the things I used to lug along. Other guys used to carry other things. One chap, for instance, used to take along pen, paper and envelopes. Sure! Do his letter writing while waiting for action.

No Identification!

However, that was just an unusual stunt. Don’t get the idea that it was general practice. And also don’t get the idea that the box was big enough to hold a couple of spare props and
a tire maybe. And also, take it from me, you did not carry anything that would be valuable to the enemy if captured. I carried the girl friend’s picture, but I didn’t carry any of her letters to me.

No, smart guy, not because I was afraid the ship would catch fire! Simply because they were identification, and might contain information of something seemingly unimportant, but perhaps most important when pieced together with what the enemy might already know.

In other words, we carried in the box, or on our person, nothing that would divulge information to the enemy.

I Call It Laziness

MAYBE you’d call this next item comfort, but I call it just plumb laziness. It was a flight leader’s trick. As you know, a flight leader has to keep his eye on the ships back of him, just as much as the other lads have to keep their eyes on him.

So this bird, in order to save wear and tear on his neck, got hold of a piece of looking glass and fastened it near the top of his right rear center section strut. Yup, a rear view mirror for airplanes. And believe it or not, the thing worked swell—so he claimed! (See Fig. B.)

Another idea for comfort, and a thing that was mighty useful in a dog scrap, was a pair of shoulder straps fastened to the sides of the cockpit seat. (See Fig. C.) As you know, every ship had the regular safety belt that fastened about your waist. That was okay for level flight, but should you get hung in a loop, gravity would start to slide you out and pull your feet off the rudder bar.

So we installed two straps; one that came up the back and over the right shoulder and down the left side of the seat, and the other came up over the left shoulder, crossed the other at your chest, and down to the right side of the seat. Thus you were held back by the safety belt, and held down on your seat by the double straps. Naturally, snap fastenings were used, in case you had to get clear fast—like in thr event of a forced landing.

It’s All How You Look At It

Yup, our motto was, comfort east or west of No-Man’s-Land. Of course, it wasn’t like home. We did get our feet wet now and then. However, in case the Grim Reaper ever reached out for us, we kind of planned it so we’d at least die on a full stomach. For the lads on the ground shoving about the trenches, such was not the case. They had to take it on the chin day and night.

Yet, after all, it’s the way you look at it. The doughboy in the trench looks up at the aviator and says, “Cripes, that damn fool up there with nothing to hang onto!” And the pilot looks down and says, “Cripes, that damn fool down there with nothing but mud to sit on!” And, so what? As far as I’m concerned, it’s, so long!

FROM the pages of the November 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Things to Inspect

by Robert Sidney Bowen (Sky Fighters, November 1933)

A WHILE back I told you buzzards a few things about knocking engines. In other words, some reasons why the engines of the old war crates used to pass out oil us now and then, and sort of leave us in the soup. Well, today I’m going to talk about things that could happen to the plane, and likewise put us in the soup.

I believe I’ve only mentioned this fact about seven million times, so I’ll just say it again—taking good care of your ship was about fifty percent of the war pilot’s job. Now, when I say, taking good care of your ship, I don’t mean being easy with it when you’re in a dog scrap. At a time like that it’s a case of your life or the other chaps, and naturally you have to take a lot of chances that you wouldn’t take if you were just buzzing around on a little joy hop. And when I speak of taking a lot of chances I mean forcing your ship to execute maneuvers that it may not be able to stand—and as a result, tear itself apart in mid-air.

Good Pilots Don’t Take Chances

But here’s the point—good pilots didn’t take chances with their ships! And why? Well, buzzards, for this reason. A good war pilot knew his ship from prop boss to tail skid. He knew from experience in the cockpil just what it would do, and just what it wouldn’t do. And how come he knew all that? For the simple reason that he cared for it as a mother would care for a new-born babe. And naturally enough! Gosh almighty, a war pilot’s ship was the difference between life and death for him.

But enough of that stuff. What we are chinning about right now, is what used to happen to war crates, and why it did happen.

Three Important Parts

GENERALLY speaking, there are three parts of an airplane that can fail and as a result cause a lot of trouble, to say nothing of causing the death of the pilot. And those three parts are, the wing fittings, the landing gear (undercarriage) and the controls. As I said in the beginning, we’ve already talked about the engine, so we’ll leave that very important part out of this meeting.

Okay, first the wing fittings.

In a biplane (and all pursuit ships at the end of the war were biplanes) there were at least four, and in many cases eight, wing fittings, or wing bolts as they were sometimes called. And if you want to count in the aileron bolts, that’s eight more.

Now just a minute, don’t get so doggone impatient. I know what you are going to ask. Just what is a wing fitting, eh? Well, a wing fitting, or wing bolt, or wing attachment bolt (all the same thing) is simply the bolt hinge by which a wing is fastened to something else.

Take the top span of a biplane, for example. It is made up of three parts. They are, the left top wing, the center section, and the right top wing. Now, the center section is solid.

BY THAT I mean it is attached to the fuselage by struts and cross bracing wires. But the left and right top wings are hinge bolted to it on their respective sides (Fig. 1). The inner end of the wing is a solid rib. (Not holed out for lightness like the rest of the ribs in the wing.) Into that solid rib is fitted the forward and rear spars of the wing. The same thing is true of the spars in the center section. So that makes re-enforced solid pieces coming together. In other words, something strong against which you can fasten the hinge fittings.

Hinge Fittings Varied

Now the hinge fittings varied in different types of ships. But the one used quite a lot was like the one in Fig. 2. As you can see, the two parts of the hinge simply slide together and the bolt is slipped through the holes and held in place by a cotter pin at the rear end of the bolt.

With reference to the lower wings, the idea of attachment is exactly the same. Except, of course, you fasten the left and right lower wings to the left and right lower longerons of the fuselage. In some planes, though, the left and right lower wings were all one piece. That is, the spars extended right through the fuselage, and the whole thing could be fastened solidly to the fuselage.

If the wings are hinged, why don’t they fall down? Because of the wing struts and wing cross bracing wires.

No Danger of Sagging

AERODYNAMICALLY speaking, the top and lower wings of a biplane are a solid piece in themselves. When the struts are put in, and the wings are tightened up there is no sagging strain on the wing attachments. So although they may only be fastened to the body of the ship, and to the center section, by small bolts, there is no danger of them sagging in flight or on the ground and pulling the wing fastenings loose.

No, not if the pilot of that ship knows his onions and has a good rigger (name given to the mechanic that is responsible for the rigging of the ship). However, if the pilot is slipshod, and the rigger doesn’t give a darn, a lot of things can happen. To begin with, the wing fastening bolts should be put in from front to rear, and the cotterpin should be in place. If not, then engine vibration is apt to shake the bolt out, and if it does—wham, your wing tears itself off.

Another thing, the cross bracing wires between the wings should be neither too loose nor too tight. If they are too tight, extra strain cahsed by violent maneuvering in a dog scrap might make them part. And if enough of them do that, your wings will just naturally fold up on you, and you’ll get no more of mother’s cooking.

The Turnbuckle

AS YOU probably know, the cross bracing wires are adjusted by turnbuckles. And a turnbuckle is simply a rod, tapered at both ends, a hole through it in the middle (to enable twisting), and a threaded hole at each end.

For the idea look at Fig. 3. The turnbuckles are fastened by wire at one end to the strut stubbs and the other end is fastened to the wire that is to do the bracing. Naturally, excess strain, vibration, etc., can make turnbuckles untwist a bit. And the result is a slack bracing wire.

And so, with reference to the wings there are several things that the good pilot takes care of and inspects every time he lands after a scrap. And lots of other times, too. He makes sure the bolts are in right. He makes sure that the locking cotter pins are in the bolts. He makes sure that the turnbuckles have not untwisted. And last but not least he makes sure that all those parts have enough grease on them and have not become rusted (and thus weakened) by exposure.

If he doesn’t do those things, he will be flying a weakened ship, that looks strong enough on the surface, but which will fold up on him some day.

The second part of the ship that needs constant watching is the landing gear or undercarriage.

What “Split Axle’’ Means

THE ships of today have what are known as split axle landing gears, and most all of them are equipped with Aero shock absorbers. By split axle we mean just that—the axle is in two parts, hinged in the middle, with the middle part higher than the two ends, so that the axle can spread outward due to the weight of the ship above it.

But, the war crates had solid axles with a wheel at each end. The axle went through vertical slots in the landing gear struts, and was held in place at the lower end of the slot by rubber cords. Thus when a ship landed the axle would try to travel up the slot in the landing gear struts, but the rubber cord would tend to hold it back. And the result was that most of the shock in landing was absorbed by the wound rubber cording stretching. Perhaps you’ll get a better idea of what I’m talking about by glancing at Fig. 4.

Of course, the wheel was fastened to the axle by a nut with locking cotterpin. The axle was stationary and the wheel revolver about it.

Now, a bad landing could weaken the rubber cording. A bum pilot might leave the locking cotter pin out of the nut on the end of the axle. A bum pilot might forget to change the rubber cording when it got too old for good use. And a bum pilot might weaken his landing gear cross bracing wires and not trouble about it.

Here’s What Could Happen

AND if he did, here’s what could and probably would happen. He might lose a wheel when taking off from bumpy ground.

His whole undercarriage might fold up on him sometime when he made a bad landing. A wheel might buckle when making a cross-wind landing. And if the rubber on one side gave way, the ship would be flung over that way when he landed, even if it was a good landing. And the result of any one of those things happening would be a nasty ground loop, if not a direct crash.

And just to show how dumb even yours truly can be, I’ll admit that once I lost a wheel while taking a Spad off. What happened? Well, a Spad always lands like two tons of brick, even with two wheels on—and with one gone, well, I plowed up enough of that drome to plant a year’s supply of potatoes, and it was a couple of weeks before all the skin grew back on my face.

And now for the third, and yes, the most important part to keep your eye on. Naturally, I mean the controls.

You can have a bum engine, you can have a badly rigged ship, and you can have a weakened undercarriage, yet somehow you can manage to get down, and probably walk away from the wreck. But—and that’s a big but—if your controls go cockeyed, you might just as well buy yourself a oneway ticket to the Pearly Gates. Or at least become resigned to a long stay in a little white cot in some hospital.

As I told you sometime ago, the controls of an airplane consist of the rudder bar and the joystick. The rudder bar works the rudder, and the joystick works the elevators and the ailerons. Naturally, they work them by the means of wires. To the right side of the rudder is a wire that leads back to the horn on the right side of the rudder. The same thing on the left side. Now, from the joystick four wires lead back to the elevators. Two for the top and bottom of the right elevator, and two for the top and bottom of the left elevator. Also from the joystick, wires lead out to the ailerons.

Now, just how many control wires were used, and how they were lead out to the various control surfaces, depended upon the type of machine. But, on any type of ship, turnbuckles were used for tightening or slackening, pulleys were used where the wire had to go around a bend, and leather guides were used wherever the wire unavoidably rubbed against something.

Wires Constantly Moved

Naturally it follows that the wires were constantly being moved while in flight. That means that some of them were constantly sliding around on pulleys, and others were constantly rubbing against leather guides.

Contact means friction, and friction means wear. Added to that was the strain of violent maneuvering, the full force of which was instantly transmitted to the turnbuckles and the wire eyes. (See Fig. 3.)

Now if the pilot did not take constant care of his controls he was simply flirting with his life. For example, take the pulleys. (Fig. 5.) Dirt, grease and other things such as dope flakes, could very easily jam them so that they would not turn. As a result the wire would slide around it, instead of the pulley revolving with the wire. Naturally the wire couldn’t stand that very long—and suddenly it would give way, and the pilot would be helpless to use his ailerons.

In other words, lateral stability would be all lost. In most planes the pulleys were inside the wing, and you got at them by unlacing a bit of the fabric. Doing that little thing was tiresome, but lordy how important!

The leather guides wore out very quickly and if they were not replaced with new guides you might find that your control wire was rubbing against a fuselage cross-bracing wire. And you can figure out for yourself what happens when steel cable rubs against steel cable. An example of where and how leather guides were used will be noted in Fig. 6.

And as for the turnbuckles and wire eyes. Well, the same points hold true for them as for cross-bracing wire turnbuckles. Get the wires too tight and a savage loop might part them. Let them get rusty and the eyes might pull out of the turnbuckles, or the turnbuckle itself give way. And so you make sure that there is plenty of grease on them to insure no rust.

AND that, incidentally, goes for the control wires themselves. They should always have a light coating of grease to prevent rust. And for a thorough inspection, the good pilot always runs his fingers along the wires, to see if they have become weakened by a strand or two parting. And when your finger suddenly gets a pin prick, stop, look and be a bright boy. Take out the whole wire and replace it with a new one. One strand breaking does not mean death is coming to you. It simply means that the wire has been weakened just that much—and maybe the other strands will let go when you’re ten thousand feet up.

Pay Attention, Buzzards!

Well, you’re all asleep now, so I guess I’ll go home. But remember this (if it’s possible) your engine is important, but so is the ship itself. It may seem like a waste of time to crawl all over it with an eagle eye each time before you go up. But listen to me, buzzards, I’ve seen plenty who figured it a waste of time, and took a chance. Well, they lost. I’m a scare-cat—I hate to take chances—maybe that’s why I’m still able to admire the trees and the flowers and other things in life on this man’s planet!

FROM the pages of the May 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Why It Flys

by Robert Sidney Bowen (Sky Fighters, May 1933)

ALL RIGHT, you buzzards, sit up and take a good look at that young chap sitting over there on the right side of the room. See him? Well, take a second look, because there is one intelligent young man. You said it! Why is he so bright? Well, wait until I read you a letter that I just got from him—

Dear Uncle Wash-Out:

    I’ve been listening to your chin-jests since they first began many months ago. I don’t suppose that your head can get any bigger, so I’ll risk saying that I have enjoyed every word, including the periods and quotation marks.

    And so, I’m going to take advantage of your offer to ask a question. Here it is. The title of your chin-fests is, “How the War Crates Flew.” Well, how did they? In other words, Uncle Wash-Out, just what makes an airplane fly?

    Here’s hoping that you’ll give us some dope regarding the technical side of the actual flight of an airplane.

                                Hopefully yours,
                                    Charles Barringer.

Well, here I am, Charlie, in the flesh, and all set to grant you your wish. So pay attention and never mind if some of these other buzzards fall asleep. It’s bright lads like you that I like to help out. The others can go walk into a revving prop if they want to. Guess we’ll never miss them, much.

And, so here we go.

The air that we breathe and feel and know is all around us has weight, and it exerts pressure in all directions. Now, the action of air on a kite results in the air being compressed underneath it, and a vaccum being formed above it. That action causes the kite to rise for the simple reason that there is increased pressure on the underneath side and decreased pressure above. To get a good idea of all that, take a look at Fig.1.

FLIGHT is secured by drawing, or propelling, an inclined plane through the air, with the plane inclined upwards and toward the direction of motion. When I speak of plane in that instance I mean a flat plane, not an airplane.

Now, that plane going through the air has four forces working upon it. And those four forces are Lift, Drift, Gravity, and Thrust.

Lift, as the word itself explains, is the tendency for the plane to rise. And that tendency, as I explained above, is the result of increased pressure underneath the plane, and decreased pressure above.

Drift, or as it is often called, Resistance, is the reaction due to the action of propelling a plane through the air, thus retarding its motion. Drift is caused by the eddies of air which hinder the forward motion. You might almost call it a backward suction or drag. And then, too, there is drift, or resistance, caused by the frontal area presented toward the line of flight. To decrease drift as much as possible the thing to do, of course, is to streamline the object that goes through the air.
Take a ball for instance. Fig.2. The air slips around the ball all right, but the vacuum at the rear causes air eddies and these eddies more or less try to suck the ball backwards. And that, of course, hinders the forward flight of the ball.

Now take a look at Fig.3. We have put streamlining on the back of the ball. The result is that the air stream follows along the streamlining, and as a result of there being no vacuum, no eddies are formed to try and drag the ball backwards. Of course, you must understand that I’m speaking generally. There is not as yet, an airplane wing of one hundred percent non-drag efficiency. There is still a small vacuum and there are still eddies caused by that vacuum. But streamlining reduces air resistance to a minimum. And of course not only are the wings of a plane streamlined, but every other part of it. However, what I’m pointing out is how streamlining helps to reduce resistance or drift.

The third force is Gravity, or to be brief, the magnetic attraction of the earth to all things on it and above it, for at least a distance of fifty miles, maybe more. Scientists have not yet determined exactly how high above the earth the force of gravity extends. However, we know that this thing called gravity is an invisible force that draws things earthward.

Thrust is the forward force applied to the plane by the engine actuated by the propeller. Now the prop may push the plane through the air, or it may pull it, but no matter which it does the action is referred to as “thrust.”

What’s that? Each of those four forces has its opposite? Right you are. Good lad, for figuring that out. Huh? What does he mean? All right, listen.

In plain words the four forces are, upward, downward, forward, and backward. The thrust has its opposite, which of course is drift. And lift has its opposite which is gravity.

NOW, when the engine is off and the plane is on the ground, drift overcomes thrust and gravity overcomes lift. In other words there is no thrust or lift, which is only natural.

And so we start the engine, run it up full out and what happens? Thrust starts to overcome drift, and lift starts to overcome gravity. Eventually the action of lift overcoming gravity points the nose of the plane into the air and the plane rises. Now, so long as your engine is on, the thrust remains the same, regardless of forward speed. However, the greater the forward speed the greater the action of drift.

Maybe that last confused you a bit. How could thrust remain the same, and yet have forward speed increase so that drift increases also? Well, it’s this way. If you were flying into the wind your prop would be trying just as hard to pull you forward, but your speed over the ground would be reduced, and naturally the drift increased. But if you were flying with the wind your ground speed would be increased (because the wind helped blow you along), even though the thrust remained the same.

You probably noted that I put emphasis on the words, ground speed. Well, an airplane in flight always has two speeds. One is air-speed and the other is ground-speed. Now, take a look at Fig.4. A lot of folks get mixed up about the speed of an airplane. And as we all know, a lot of fiction authors go a bit haywire about it. However, as you will note from the figure, air speed is always the same. That is, of course, provided that you keep the throttle in the same place. And I might mention right here that air speed means the speed at which the wings pass through the air. No matter whether it is fifty miles an hour or five hundred miles an hour, it will stay the same in level flight. But the ground speed, the speed at which the plane travels over the ground, is always changing. If there is a twenty-mile wind and you fly into it, your ground speed is reduced twenty miles per hour. And if you fly with that wind your ground speed is increased twenty miles an hour.

So remember, when some one says, “This ship will do 200 m.p.h.,” that he means that the wings will go through the air at that rate of speed. Its speed over the ground will depend upon whether he flies with the wind, or against it.

Now in case you get the idea that I’m suggesting that well-known airplane speed records don’t mean a thing, just let me clear up that point. A straight-away record is taken from the average of two flights with the wind and two flights against it. Therefore the thing is balanced and you get the speed of the plane as though it were flying in still air. And the same holds true for a closed course speed record. One half of the course would be with the wind, and the other half would be against the wind. Get the idea?

BUT we happen to be up in the air just now, and talking about the four forces that are having their own individual effect upon the flight of our ship.

We said that thrust remains the same regardless of speed, but that drift increases, with increased forward speed. Right! Now, it is only natural that drift increases also as the forward speed is reduced. And when the drift is greater than the thrust what happens? It means that gravity has also become greater than lift. The result is that the plane goes earthward. If such a thing happened suddenly and the increase of drift and gravity over thrust and lift was of a great amount, the plane would naturally stall, and thrust and lift would be non-existant for the moment. In other words the plane would start toward earth, out of control until your falling speed became great enough to be flying speed.

That may sound a little complicated. But what I mean is that a plane stalls because drift has become greater than thrust and gravity has become greater than lift.

Huh? What about gliding down?

Now keep your shirt on. I can’t say everything in the same breath. I’m coming to that point right now.

You are flying along and you decide to land. Well, the first thing you do is throttle your engine. That, of course, is an automatic decreasing of your thrust. If you carried straight on at level flight drift would soon take complete charge of thrust and gravity would take complete charge of lift—and you would stall. So you point the nose downward, and let drift gradually overcome thrust and gravity to gradually overcome lift. Of course you take care of that sort of thing with your gliding angle. And then when you get right close to the ground you level off and go straight forward. That, of course, causes drift to overcome thrust (which now is simply gliding speed) at a faster rate. And the same with gravity overcoming lift. Presently thrust and lift become practically non-existant, and your plane stalls—but—you are only a couple of feet off the ground so you simply settle on the ground with no damage done. So in theory, every airplane landing is a stall—drift and gravity, having completely overcome thrust and lift.

Now, that is the general action of the four forces, thrust, lift, draft, and gravity, upon an airplane on the ground and in the air. And, therefore, it means that an airplane flies when thrust is equal to drift, and lift is equal to gravity. When those things are equal momentum carries the plane on. Increased thrust means increased air speed. And increased lift, means increased climbing angle.

Now, before I toss you all out, I’m going to say a few words about the design of airplane wings in regard to lift and drift.

THE length of a wing is called the span. And the width of a wing is called the cord. The relation of the span to the cord is known as the “aspect ratio of a wing.” A square wing would have a low aspect ratio. Whereas a narrow wing would have a high aspect ratio. See Fig.5. Now a high aspect ratio is better than a low aspect ratio for the simple reason that it gives the same amount of lift with less drift.

Now a flat wing, as we know, would have a lot of drift, regardless of its lift. So to lessen the drift the wing is itself streamlined. In other words it is changed from a flat wing to a cambered wing. And because it is cambered the air pressure on its underneath surface is at right angles to it. See Fig.6.

The curvature of a wing determines its lifting efficiency. (We are disregarding streamlining and drift for the moment.) A flat wing has less air pressure beneath, and as a result less upward lift suction on top. As the wing is curved more, both of those things increase. Naturally there is a limit, and aeronautical engineers are continually experimenting for the correct camber of the wings of the planes they design. But the curvature, particularly the curvature at the top is a mighty important item regarding the lifting efficiency of the wing. In the old days it was believed that a wing got its greatest lift from the bottom of the wing. But the wing design developments of recent years have proved that almost sixty-five percent of the lift of a wing is from the top. So camber is not something to toss out the window. Upon it depends maximum lift efficiency, in accordance with the correct angle of incidence (angle of wing toward line of flight).

And so, you might say that the wings of an airplane are the most important. You can always get a good engine, and you can always build a good fuselage, and the other things that go with it. But when you come to the wings, you have a real job on your hands. They have got to be strong enough to stay on when you are going full out. They have got to have maximum lift for the weight they are carrying, and they’ve got to have minimum drift, because you get more drift from your wings than from any other part of the ship.

But after all, drift is only one of the forces you’ve got to think about. There are three others, as I told you—lift, thrust, and gravity. Keep them all in mind, when you design that plane. And remember, thrust has got to equal drift, and lift has got to equal gravity, or you’ll never fly in a hundred thousand years!

FROM the pages of the April 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Dizzy Doings

by Robert Sidney Bowen (Sky Fighters, April 1933)

WELL, being as how you buzzards are still kind of young, far be it from me to try and shove too much knowledge into your heads. So I guess I’ll devote this chin-fest to dizzy doings of war days. Naturally, we heroes, who restored France for American tourists, were only human after all. Which is but another way of admitting that now and then we cut loose from the conventional type of war flying, and had a little fun for ourselves.

Of course, nowadays, it wouldn’t exactly be called fun. As a matter of fact, it would be called rank violation of Department of Commerce (Aeronautics Branch) rules and regulation. But in the old days when you tried dizzy stunts, just for the heck of it, the only risk you ran, outside of handing in your chips to the grave digger, was maybe a burning up by the C.O. in case you missed calculations and wrapped your ship around a tree, or an estaminet, or something. But it was good fun, anyway, and as I look backward over the years I can visualize again some of the darndest, dizziest plane stunts imaginable.

And so, put your note-books and pencils away, and lean back—and don’t snore too loud. As a matter of fact, you’d better stay awake, because I’ll probably slip in a technical explanation here and there as I go along. And if you miss it—well, it’ll just be too bad for you, and how!

One of the most miraculous, and dizziest, and funniest stunts I ever saw pulled, happened at an airdrome in England. As a matter of fact it was at London Colney Airdrome, about seventeen miles north of London. There were several large-sized hangars on that field. One of them was set at right angle to the others. By that I mean that both ends opened onto God’s free air. There were no obstructions at the front or the rear. Well, one day one of the boys thought up the swell idea of “shooting” the hangar, as he called it. He had all the ships taken out and both the front and rear doors rolled wide open. And then he took a ship up and came down and flew through the empty hangar.

Naturally, the rest of us had to take a crack at it ourselves. There was a reasonable amount of clearance all around as you went through the hangar, so it wasn’t particularly tough. And besides, none of us had just gone solo the day before. We had a few solo hours under our belts, you know.

WELL, from that day on, “shooting” the empty hangar became a regular part of a follow-the-leader game. But, one day one of the boys (I won’t mention his name as he is alive and still eating three squares a day) decided to shoot the hangar all by himself. When he took off it was empty, and both front and rear doors rolled back. But, it so happened that a grease ball, not knowing the pilot’s intention, rolled the rear doors to within about ten feet of being shut. Just why he ever did it, we never found out. But I’m positive that it wasn’t on purpose. That particular grease-ball was too dumb to ever do anything on purpose.

Of course you can guess the rest. Down comes our boy friend toward the front end, which was open. Well, imagine his embarrassment when he gets inside! Naturally there is nothing to do but keep going. Which he does, heading for the ten-foot opening. And he goes through, hell bent for election. The result is, that he leaves his wings inside the hangar, and comes out into the open like a launching torpedo. However, the good Lord must have been riding the cockpit with him, because he streaks across the field and finally rams into a stone wall on the far side. We pick him up out of the wreck, out cold. But in an hour or so he’s all set again to carry on with the war. Needless to say, he never tried the stunt again! Those of us that were there, and saw him go in with wings on and come out with them off, haven’t stopped laughing yet!

Perhaps the dizziest, and yes, the dumbest stunt ever tried, was pulled off shortly after the signing of the Armistice. As the squadrons were moved up toward the Rhine and the Army of Occupation, some of us were made ferry pilots, and given the job of flying all obsolete planes to Lille for dismantling and ultimate destruction. New types had been sent out to replace them, so rather than fly them all the way back to England it was decided to concentrate the bunch at Lille, salvage the instruments, and maybe a few parts of the engines, and burn up what was left. Well, we ferry pilots went all over France collecting these ships, and some of them were in pretty good shape. As a result we held what was called a “Fly the Fabric Off” contest. Five or ten of us would each select a pretty good ship that was doomed for the bonfire. Then we’d take a knife and slit the leading edge of the wing fabric on the lower wings in several places. Then we’d take the ship up and stunt it with the idea of trying to-make the prop-wash catch under the slits and rip the fabric off in strips. The winner was the one who landed with the most ripped fabric trailing back off his wings. And believe me, buzzards, there was plenty and don’t think there wasn’t. The strangest part of it all, perhaps, was the fact that during the two weeks that we conducted the contests (before the C.O. at the field clamped the lid down on our dizzy actions) not a single one of us crashed, or even ruffled the part in his hair.

OH, all right, all right, I know! Luck is always with fools and drunks, and we weren’t drunk at the time.

But speaking of drinking. Here is a story that I can vouch for as being true, although I was not an eye witness. And, incidentally, it is not a yarn of which war birds can be particularly proud. But it actually did happen, and I never did pose as a war pilot who wore a halo around his head; so I’ll tell it to you.

It seems that a certain squadron had had a terrible binge, and one peelot took about five times as much as was good for him. Well, that pilot was down for an early morning show, and his orderly had the devil’s own job trying to wake him up out of his cognac slumber. Finally, with the pilot mumbling incoherent protests, they carried him out to his ship, dumped him in the cockpit and told him to get going. Perhaps he was partly revived, or perhaps it was flying instinct, but at any rate he took off with the flight, went over the lines, got into a scrap, nailed a Hun and came back. When he landed he stumbled out of the ship, and reeled into his hutment and went back to sleep. About two hours later he came tearing out, goggles and helmet in one hand, and sidcot suit half on. He tore for the hangar line, didn’t see any ships on the tarmac, and whirled on the Flight Sergeant—and bawled hell out of him for not waking him up in time for the dawn patrol! To this day (he’s still alive) that pilot has no recollection whatsoever of making that flight and shooting down a Hun!

And there you are. Take it or leave it! I won’t be sore, either way!

Many times dizzy and funny things happen when the pilot in question is trying to do the best he knows how. Your own dear Uncle Wash-out was the innocent victim of such an event on one occasion.

Now, never mind that wise-crack, you! Perhaps it was on more than one occasion. But I’m just chinning about this one, see?

It happened when I was with the squadron in Egypt, the year after the war. We’d been sent down there from Germany to—! Heck, this isn’t a personal history, so let that part go. Anyway, we were stationed at a field called Abukir, just north of Alexandria. And one of our jobs was to keep watch over an evacuated drome at a place called Amiria, way the heck out on the desert. There was stuff there that the Bedouins (desert gypsies) might steal, so we took turns staying at the place and guarding it. It would be two pilots, with a two-seater, nine men and one non-com for two weeks at a time. The relief would be made by ground transport for the men, and by air for the pilots.

WELL, one time my buzzard buddy decided to ride back with the men. So I took the air route telling him to be sure and get my battered suitcase into the lorry. And, of course, when he finally arrived at our home field, some ten hours after I did, he confessed that he’d forgotten all about my suitcase. Well, that wasn’t a serious enough crime to cut his throat for, so I left him alone and next morning took one of our spare “play-jobs”—a single seater Sopwith Pup that we used to play around with—and flew out to Amiria to collect my suitcase. There is still plenty of room in the cockpit of a Sopwith Pup even when I’m in it, so instead of going to the trouble of lashing the suit case to the center section struts, I simply tossed it in the seat and used it as a back rest.

A Sop-Pup is rigged to climb all the time, so I got off the ground without really realizing just what was going to happen. But when I got back to my home drome I sure realized—and how! And it was just this—because of the suitcase at my back I could not get the stick back far enough for leveling off and landing, tail down. I could glide down all right, but the only way I could get it leveled off was to shove the throttle forward, and let the inherent climbing qualities of the ship bring the nose up. But even then I couldn’t do that close enough to the ground for even a “pancake” landing.

AND there I was, in the air and unable to land. I tried ten thousand, million times to reach my hand around behind me and pry the suitcase overboard. But the Devil, himself, must have been sitting on it. It was with me, and was darn well going to stay with me. I circled the field for over an hour, and no soap. By that time the entire squadron was grouped on the tarmac wondering why your Uncle Wash-out loved the air so much that he stayed up, when eggs and bacon and coffee-cognac were waiting for him in the mess.

Well, to make a long story much sooner, I finally convinced myself that me and a crash had to get together eventually, so why not now? Of course, after some three years of war flying, I’d been able to get this thing called crashing right down to a science. So I figured the best way, and decided that a lone date palm on the edge of the drome was the one and only answer to my prayer. So I glided for it as slow as I could. I practically loafed through the air. And by the time I reached it I was just about ready to stall. I’d maneuvered so that my left wing-tips would catch the trunk, about ten feet up; they did, and the result was exactly as I had figured. The wings wrapped themselves about the trunk, and the rest of the plane, with me still in it, revolved about the trunk until the whole business “mushed” onto the ground. There was no Murad handy to light up, so I simply climbed out of the wreckage and pulled out that damned suitcase after me. Not a scratch on me. I was hardly even shaken up. But the plane was a mess; just matchwood. Real clever, eh. Oh, yeah? Well, you should have been there to hear what my C.O. told me! It took him ten minutes, and he didn’t use the same word twice! After that I carried my toothbrush in my sidcot suit instead of in a suitcase.

LIKE all the other branches of armed service the flying end was no exception when it came to pulling dumb things. One of the dumbest that impressed me the most, was the way the “powers-that-were” selected pilots for different types of work. If you weighed nine hundred pounds and stood eight feet, six inches tall, you were usually assigned to scout work in ships that you could practically carry under your arm. But if you were of midget proportions they put you on a twin engined bomber that would take you from Sunday to Thursday to get into.

Of course, when I say “usually” I’m really stretching it a bit. However, there were several cases of the right pilot being assigned to the wrong ship. So the idea is worth the yarn, anyway.

IT’S a yarn about an old buzzard buddy of mine who was so small that he had to reach up to touch the top of a straw hat on the ground. Honest, he was knee high to a grasshopper. But don’t worry, the lad was plenty dynamite when Huns came around. Anyway, the big boys must have looked at him through a magnifying glass because they selected him for day bombing, and sent him out to the field where I was busting up ships. Well, it became my job to teach him to fly. Even in the good old training ship, the “Avro,” he had to use two cushions in order to be able to see over the forward cockpit rim. And even then he had the Devil’s own job trying to reach the rudder bar. But he was one game guy, and he learned fast, I’m telling you. His first solo was perfect, and he continued to do damn fine work in the air.

And then one day, Fate must have given him a kick in the slats. He was up-stairs just practising when, zingo! . . . both his cushions slid off the seat! He couldn’t get them back on, and he couldn’t see over the cockpit rim except by standing up. And when he stood up, he naturally couldn’t get his feet on the rudder bar. Well, the lad sure was in one hell of a fix. But he did the best he could. He throttled the gun, went out of sight in the cockpit to tap the rudder, and got the ship headed down toward the field. Talk about your one-arm paper hangers! That lad was a dozen of them rolled into one. But unfortunately, it wasn’t the day for medals for him. He made a valiant attempt at a pancake landing, but by the time he could get the ship set, the airdrome had slid past him . . . and down he came, level as a billiard table, and right smack onto the roof of the squadron office. And, my dear little buzzards, the C.O. in the flesh was inside. The result was one squadron office gone to hell, one Avro gone also, one midget pilot unhurt but frothing at the mouth, and one C.O. with ten years off his life, and not knowing whether to commit murder, or laugh it off.

P. S. He laughed it off. He was that kind of a reglar guy.

And, then there was the case of a. . . .

OH, oh! Here’s our C.O. and the glint in his eye doesn’t indicate that he’s going to do any laughing. If he asks questions, just tell him that I was explaining the wing co-efficient of an S.E.5 as a means of determining the lift-drift ratio of the U.S.S. Akron. Maybe he’ll believe you at that! S’long!

FROM the pages of the March 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Just How Fast?

by Robert Sidney Bowen (Sky Fighters, March 1933)

WELL, my Fledglings—er, sorry, I should have said Buzzards! Well, anyway, the chin-fest this time is going to be one which I am afraid will shoot a pet belief of yours all to pieces. By the time I get through, you birds will be calling your Uncle Washout all sorts of nasty names, and the main one will be—“liar”! But I’ve been called that by dumber buzzards than you (yes, there are a few I think) so don’t build up any hopes of getting my goat. A Sopwith Camel got that, years ago! However, I’m warning you in advance. If you don’t believe me, then get up and walk out. It’s all the same with me. But, if you do stay, keep your traps zippered up until I’ve emphasized the final period and quotation marks.

I’ve been planning to chin this tune to you for some time, but I’ve delayed doing it until we got to know each other a little better. That is, rather, until I got to know you a little better! Well, I’ve found, according to your letters, that your bark is worse than your bite. And so figuring that though you may toss things my way, when I’m through, my one and only life won’t be hanging in the balance.

So, here it comes. Ever read anything like this?

“Slamming the stick over and stepping hard on left rudder, Jim Collins, keen-eyed eagle of Uncle Sam’s brood, spun around on wing-tip and went thundering straight for the Fokker at a speed well over 200 m.p.h. His twin Vickers yammered harshly, and—”

AND horse collar to you, Jim Collins! And also, horse collar to you, Mr. Author, who lets that sort of stuff drip off your typewriter keys!

You guessed it, Buzzards! I’m going to chin about the speed of all the war flying crates that I and 9,999,999 other dumb peelots made famous. Yeah, I can see that look slipping into your eyes, already. But go ahead—I’m going to chin the truth, the whole truth, so help me!

Jim Collins, or any other pilot during the late mix-up, never went even 200 m.p.h. in level flight. Now when I say, the late mix-up, I’m talking about the World War. Perhaps there’s been another since then, and no one has told me about it. But the World War I mean, is the one that took place between 1914-1918. And during those years no war crate, Yank, British, French, German or Ethiopian, came within 50 miles of a top speed of 200 m.p.h!

All right, all right, sit down! Let’s start right in with the year of 1914 and take a look at the records year by year.

The War, as you all know, and if you don’t, I’m telling you, started in August, 1914. Now up to that date the speed record for land planes was 105 m.p.h., made by Maurice Prevost when he won the Gordon Bennett Cup Race held in France, September 29, 1913. And the speed record for seaplanes was 86.8 m.p.h., made by C. Howard Pixton wrhen he won the Jacques Schneider Maritime Aviation Cup Race (original name of the present Schneider Trophy Contest) held on the Bay of Monaco in March 1913.

Therefore we enter the World War with a top speed of 105 m.p.h. But, don’t overlook the fact that that was the top speed of the fastest racing plane. Not a military ship loaded with guns, ammo, and a bomb or two here and there, but a racing ship stripped of everything possible that would hinder forward progress, and with an engine tuned up for that one race!

Okay, now we turn to the records.

The British sent to the front in the 1914 period, first, the well-known Avro, powered with a Gnome or Le Rhone with a top speed of 65-70 m.p.h. Then there was the B.E. (Bleriot and later the British Experimental) powered with a Renault, that knocked off about 50 m.p.h. Another was the Gnome powered Vickers that slid along at 60-65 m.p.h. And of course the Handley-Page Bomber that had two Rolls-Royce engines, and thundered forward at about 80 m.p.h. Those ships were all two-seaters, or over, and were the vanguard of British ships in France.

Now the French had their good old two-seater Breguet that bent your whiskers back at 55-60 m.p.h. They also had the Bleriot (same as the British) that clicked at around 55 m.p.h. The well-known Caudron that mushed onward at about the same speed. And ditto for the Maurice Farman, the Morane and the early Nieuport. All were two-seaters or bombers save the Bleriot, the Morane and the Nieuport.

AND the Germans? Well, they had the Albatross scout with a Mercedes and. 65-70 m.p.h. to its credit. Then there was the two-seater Aviatik that clicked at around 70-75 m.p.h. And the Taube single-seater monoplane with an Argus engine that could only hit 50 m.p.h. and not go boom!

So taking it all in all the Germans had a general edge of about 5 m.p.h. over the French and British save for the Handley-Page with its twin engine speed of 80 m.p.h. But taking the general top speed average we find it to be around 65 m.p.h. in the first year of the war, or, to be pretty near exact, some 40 m.p.h. below the then existing world’s speed record for all types of aircraft.

Now, in case you think I’m going to go on listing all the various planes year by year, you’re crazy. Such a thing would fill this whole mag. And the C.O. tells me that there are some swell yarns he wants to put in, and for me to go easy on the space. But, I’ve started this fight, and I’m going to finish it by tracing the increase of war plane top speed right through to 1919. I’ll do it by sighting performances of the various leading and famous crates.

Naturally, no World War power made a ship one year, and then tossed it in the ash can for an entirely different design the next. True, that was done in a few cases. But what I’m driving at is that not only were new designs brought out, but the old ones were improved upon. As an example we find the original British Bristol with a Gnome in the nose in 1914 doing around 70 m.p.h., and in 1917 with a Rolls-Royce and a few improvements it did 105 m.p.h.

BUT we’re getting ahead of our chinning. Let’s go back to 1915. That year was really the year that aerial warfare got under way. Prior to then, war flying consisted of reconnaissance and bombing work. But in 1915 the boys got their hands on aerial guns and the works started popping.

The British jacked up the speeds of their old ships a little bit and sent out the first DH single-seater (DH2 Pusher) that could hit 95 m.p.h. That same year the first Sopwith Scout came out with 90 m.p.h. Then there was the first Martinsyde single-seater that made 95 m.p.h. And the fastest of all, the. famous Bristol “Bullet” that did just about 100 m.p.h.

Meanwhile the French got 90 m.p.h. out of a new Nieuport. Some 70 m.p.h. out of a Bleriot scout. And about 5 m.p.h. more out of a new Caudron single-seater. The French seemed to be a bit conservative in their speed figures that year.

That year saw the introduction of the first Fokker. It was called the “Eindecker” and was a single-seater monoplane powered with an Oberursel engine, and had a top speed of 95 m.p.h. The Germans boosted their Albatross speed up to 80 m.p.h. And that was about all they did.

So we see that in the second year of the war England has most of the speed honors. But, believe it or not, the fastest speed is still 5 m.p.h. below the record set in 1913.

However, in 1916, the scrapping nations pulled up their socks and got to work on the idea of shoving their planes through the air at a real good clip.

The British pushed their Avro single-seater up to 100 m.p.h. They came out with a new Bristol that did 105 m.p.h. They made a redesigned Martinsyde do 110 m.p.h. And they sent out the first S.E. an S.E.4 (not S.E.5) that did close to 100 m.p.h. But their greatest achievement was the new DH4 that did around 125 m.p.h. That ship was the fastest of its time.

THE French did a little better by themselves as regards speed in 1916. The most important item was that they came out with the first of the famous Spad pursuit ships. This job, which was powered with a Hispano-Suiza engine, as were all Spads, knocked off 105 m.p.h. The new Caudron twin-engine bomber did 85 m.p.h. which was pretty good for a crate of its size. And the fixed-up Nieuport equaled the top speed of the Spad.

Of course, 1916 was a big year for the Germans. The first Fokker of the famous D series saw front line service that year. Naturally, it was the Dl, and powered with a Mercedes it was good for 105 m.p.h. The Aviatik, with a Benz in the nose had the same speed. And the New Benz-powered Albatross hit the same clip, also. But strange as it may seem, the honey of German ships that year, as far as speed was concerned, was the Benz powered Halberstadt single-seater. The first Halberstadt that year was powered with an Argus and could do 105 m.p.h. But when they stuck a Benz in the nose the ship went up and buzzed along at a nice clip of 120 m.p.h.

And so, at the end of that year we find the British and the Germans pretty much on a par for speed honors, with the French tagging along slightly behind. And not only that, we find that the existing speed record for all types of aircraft has received a good swift kick in the ailerons!

Now, before we step into 1917, let me put a word in for good luck. I have been chinning about the speed of war crates. I have not made any mention of the maneuverability of war crates. So just bear that in mind as we talk on. Speed was an asset, but not the whole thing. So don’t get the idea that just because the French had slower ships that they were doing the poorest job. Far from it, believe you me! In a dog-fight a highly maneuverable ship can trim the pants off a faster ship any day in the week, assuming, of course, that the pilots are equal in skill. So don’t let your grandmother tell you different.

AND so for 1917, the year when supremacy of the air was finally decided for once and for all in the World war.

Perhaps the greatest contribution to the art of smacking things out of the sky that year was made by the British when they sent out to France the Famous Bristol Fighter. The job of that year was powered with a 200 hp. Hissi or a 200 hp. Sunbeam, and it slid along, with full load at 120 m.p.h. Next in line was the well-known DH9 with a Napier-Lion engine. This ship, also a two-seater, could do 110 m.p.h. And then came two of the most famous airplanes ever built. First the S.E.5. at 125 m.p.h., and the Sopwith Camel at 120 m.p.h. Both ships were pursuit jobs, as you all know. And—but why chin more? You know all about their history.

To match the British contributions the French brought out a new Nieuport that could do about 120 under full steam with a Gnome in the nose, and about 115 with a Hisso. In addition to that they stuck a 200 hp. Hisso in a redesigned Spad and got a top speed of 125 m.p.h.

Of course the Germans weren’t asleep, either. The first was their new Mercedes-powered Albatross that clicked at 125 m.p.h. The next was the souped-up Aviatik that made the same speed. Then the Fokker D4 at 120 m.p.h. and later the D5 at 125 m.p.h. And last, but not least, the famous Pfalz with a speed of 120.

And so we find England and Germany hitting it off neck and neck, with the edge in favor of England, due to its higher topspeed average for all types. And particularly due to the introduction of two brand new pursuit ships, the S.E.5, and the Sopwith Camel.

All of which brings us up to 1918 and the final showdown.

As usual, England got the jump by bringing out two brand new types, and improving on all the others. The new types were first the Sopwith Dolphin, a high altitude ship that could do 130 m.p.h., and the Sopwith Snipe that could do a shade over 140 m.p.h. with luck. This ship was considered by many to be the fastest thing in France at the end of the war. It came out about three months before the Armistice was signed. The principle improvement on other British designs was that made on the S.E. series. The S.E.5a came out at 135 m.p.h. Then, too, there was the D.H.9a with an American Liberty engine (two-seater) that did 125 m.p.h. And the Bristol Fighter was put up to 130 m.p.h.

The French simply boosted up the speeds of old designs. They got the Spad up to 135. And they got the Nieuport up to around 130. Outside of that, they slammed into the enemy with what they already had.

The Germans worked on the Albatross scout and got 135 m.p.h. out of it. They also came out with the famous Fokker D7, a ship that was credited with 140 m.p.h. as a top speed. And they also came out with the Fokker Triplane with a speed of about 135 m.p.h. The only other ship improved upon was the Pfalz, which was boosted up to 130 m.p.h.

And there, Buzzards, you have the straight dope on the speed of war flying crates. Mark you! I’m speaking of speed at level flight, not diving speed! That was something different. But when you speak of airplane speed, you speak of speed from here to there, not from up there down to here.

AND so—eh, what’s that? I knew it, I knew it! Why didn’t I speak of Yank planes? Well, here’s why, Buzzard, and be surprised if you will. There was not a single American designed and manufactured ship in action in France during the War. True, there was the American Liberty D.H.9a, but that was fundamentally a British De Haviland design. If the war had lasted longer, the American Thomas-Morse might have seen service over Hunland.

One more thing. What was the fastest thing in the air in France? The Sopwith Snipe, you say? Wrong, Buzzard, wrong! It was the tip of a propeller blade. The tip of a nine foot prop at 1800 revs traveled a shade over the nine and one half miles per minute! Figure it out for yourself, or ask Dad, he knows! S’long.

FROM the pages of the February 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Bombs and Bombing

by Robert Sidney Bowen (Sky Fighters,February 1933)

SIT down, you buzzards, and stay down! Any side remarks and I’ll. . . . Huh? What’s that? Why am I all steamed up? Well, just take a look at this letter. The darn thing explains itself.

Dear Uncle Wash-out:
    I think SKY FIGHTERS is a pretty swell magazine even if it does contain your stuff. But I’m just kidding about the last part. I guess you’ll do all right.
    However, here is a complaint. Wasn’t there anything else besides pursuit ships in the World War? Or were they the only ones you knew how to fly? Seems to me that I’ve read some slick yarns in this mag that had to do with bombing raids. Do you know anything about the technical side of bombing, or are you just plain dumb about that sort of thing?

Henry Craveil

Now, if Henry lived just across the street I’d sure step over and bend a couple of one hundred and twenty pound bombs over his dome. But he happens to live out in Oregon, and that’s too much of a walk for me. So I’ve just got to swallow that there insult, and try to fix Henry up the best I can. And while I’m doing it you other crash hounds can pin back your ears and get a brain full.

Yes, I’ve shoved a few bombers around in my day, and have dropped a couple of eggs here and there. Now don’t go asking me what I hit, because I promised the C.O. of this mag never to tell a lie, and I’m not going to break that promise just to maintain my glorious reputation with you birds.

But, shut up! Let’s get serious.

World War airplanes were divided into three general classes. They were pursuit planes, observation planes, and bombing planes. Of the three classes the pursuit ship was the only one that could perform all three functions. Now, when I say that, I don’t mean to imply that it was a waste of time to have observation ships and bombers in action. Naturally, each type of ship could perform its own particular job better than either of the other two. However, a pursuit ship could serve as a scouting plane, an observation plane, and also drop a total of about eighty to one hundred pounds of bombs. An observation plane could do its job of reconnaissance and drop bombs as well. And perhaps in a pinch serve as a pursuit ship. I say that because the well-known Bristol Fighter could outfly almost any pursuit ship, at least from the standpoint of speed. Another one, too, was the British DH9 powered with the Liberty or Rolls-Royce engine.

But for the sake of this chinfest we’ll say that the general run of observation ships were not good in pursuit work. The bombers, of course, were ships built for the job that the name implies—bombing. However, they could also function as observation ships, for the very plain reason that observing means seeing things with the eyes. And the crew of a bomber naturally didn’t fly with their eyes closed. However, no bomber in the World War could serve as a pursuit job, no matter how much cognac the pilot put under his belt.

LISTEN, buzzard, sit down! What?

What’s all this got to do with bomb dropping?

The answer is, nothing in particular. However, I’ve been using up breath with the idea of first pointing out how the particular job of each of the three general classes of ships used during the war overlapped each other. One of your favorite authors might tell of a pursuit job bombing a place. And you might say, “Horse-feathers! Bombers did that sort of thing!” So I’m just putting in a few words or two to save the authors’ hides. I passed out a couple of cracks at them at other chinfests, so I’ll get back in their good graces now by proving the authenticity of some of the stuff they write. Sure the emphasis is on the “some”! Think an honest war-chicken like me would back ‘em up in everything they said? Huh! I want to go to heaven sometime, you know!

Oh, yes, about bombs.

WELL, as I know, and you should know by now, an aerial bomb is, fundamentally speaking, a container full of high explosive that will detonate and explode when it comes in contact with the ground after its travel through the air. There are all kinds of sizes, shapes and mechanical functions of bombs. However, there are two features that are incorporated in any type of aerial bomb. One is to travel nose first, and the other, to detonate and explode upon contact with an object, or in the case of delayed detonation, to explode after the bomb has penetrated its objective.

In order that bombs will drop nose first, they are of course made heavier at the nose. In other words, pear shaped. To get the idea look at Fig. 1. Now, in order that the bomb will maintain directional stability (not wobble around, or go end over end) the bomb is fitted with rudders, or vanes as they are called. There may be three or four vanes, set equal distances apart at the rear end of the bomb, or I should say, the tail of the bomb. These vanes, when passing through the air, tend to keep the bomb going straight, just as the feathered vanes at the end of an arrow keep the arrow to a straight path of travel. See Fig. 2.

THERE are various ways to make a bomb explode once it strikes its objective. There are, generally speaking, certain types of bombs that have the detonator in the nose. Others have it in the tail. And still others have a detonator in both the nose and tail.

Now, of course, it is not a good idea to have bombs all set to explode when in the bomb racks of your ship. In other words they should be fitted with some sort of a safety device that will keep them from detonating themselves until they have struck the objective. Of the type of bomb I’m talking about (which was used quite generally during the war) there were two kinds of safety devices. The first was a safety pin that had to be yanked out before the detonator could strike the explosive. An idea of this safety pin can be obtained from Fig. 3. Just as in a hand grenade there was a pin that had to be pulled out before you threw the grenade.

The other safety device was a little propeller attached to the end of the detonator. If the fuse was at the tail of the bomb and the bomb exploded by the detonator traveling downward, the detonator rod was threaded so that the little propeller revolving in the air stream would eventually spin free of the rod and allow the detonator to snap down when the bomb
struck. In case you birds are still dumb about that point, take a look at Fig. 4.

Naturally, if the detonator was in the nose the little propeller was fastened to the detonator so that the air stream would spin it around and allow the detonator to move up where it could hit the fuse when the bomb struck, as in Fig. 5. And, of course, you can figure for yourself how the propellers would be set in relation to the detonating pins when-there was a detonator at each end of the bomb.

NOW, just to clear up those two safety devices, let me say that the little propellers do not function until the bomb is traveling through the air, after it has left the ship.

Yes, yes, I know. Why didn’t the little props untwist when the bomb was going through the air and still attached to the bomb rack?

Well, smarty, because there was a second pin, attached to the bomb-rack, that stuck between the little prop blades and thus stopped them from revolving. And the first safety pin that I spoke about, that passed straight through the detonating rod and prevented it from moving, even though the props were off, was also attached to the bomb-rack. So you see, when the bomb was released both safety pins were pulled loose (or rather, the bomb pulled loose from the safety pins) and the bomb went sailing down with its little props spinning, so that the detonators could do their stuff when the bombs struck.

THERE is no need of going into the explosive side of bombs. Different combinations of chemicals and powders made different kinds of explosives. We won’t try to give you a talk on chemistry today. However, there is one point I want to speak of—that’s the item of delayed explosions. For instance, if you are bombing troops and other things on the surface of the ground, you want a bomb that will explode instantly and hurl its death dealing messengers in all directions. But if the bomb must first go through armament, etc., before it can do any worthwhile damage, you naturally have got to have a bomb that will explode after contact. It’s the same principle as shells from artillery guns. And its worked out by a system of delayed fusing. In other words the bomb strikes, the detonator hits the fuse, but the main body of the explosive does not go off instantly. Of course you must realize that when I speak of a delayed explosion I don’t mean an explosion that comes five or ten minutes after the bomb strikes. A delay of one quarter of a second is long enough.

Now, just one more thing before we talk about actual bombing. The bombs that we are chinning about now are aerial bombs that are used for destructive purposes. In short, bombs that will blow the pants off your enemy, and him along with them. But, of course, there are other kinds of aerial bombs. One is the parachute bomb that you release so that it will strike and light up the surrounding country in case you are making a night landing. And the other type is the flare bomb that is used for signalling purposes. Both types arc more or less electrically operated. In other words the bomb is ignited as it passes through the air.

Like many other functions of airplanes, bombing is often all planned out ahead of time. That is, bombing of a certain objective by bombing planes. Let us say that Brigade has issued an order to a bombing squadron to try and knock the daylights out of a railhead back of the enemy lines. The first thing to figure out is what types of bombs to use. In other words instantaneous or delayed action bombs. Then comes the selection of the time to make the raid (whether daylight or at night) and how many planes to use.

NATURALLY the bombers must have a pursuit escort. Some scrapping ships to keep away the enemy should he stick his nose in and try to upset the apple cart. That, of course, is arranged by Brigade. The pursuit ships will meet the bombers at a predetermined point, escort them over, and escort them back—we hope!

Now, it must be figured out before hand, as near as possible, just how the bombing is to be done. Shall it be one ship at a time, or all at once. However, no matter what Is decided, the accuracy of dropping the bombs depends upon the speed of your plane, your altitude and the direction of the wind. By plotting those three items you can set your bomb sight so that you will have a fair chance of hitting your objective. Bomb sights of today have been worked out so that they are pretty accurate. In the late war they weren’t so good, although the boys did a darn fine job with what they had.

SOME of you buzzards think that all a bomber does is fly over its target and drop a bomb, and fly away. That’s all wrong. A bomb is released before you reach the target. And if you have set your bomb sight correctly the bomb strikes the target when the plane is directly over said target. See Fig. 6.

You ask why, eh? Well here’s why.

The plane is traveling through the air. That means that every part of the plane has a certain amount of momentum. In other words, anything that leaves the plane travels forward a certain distance before gravity can take full charge. Naturally, gravity has its effect the instant the bomb is released, but it takes full charge gradually so the downward path of the bomb is curved. (As shown in Fig. 6.) Therefore the bomb must be released before the target is reached, as it travels forward as it travels downward.

Now, if the plane is traveling into the wind its actual ground speed is reduced, though, of course, air speed (the speed at which the wings pass through the air) is constant. It follows then that when the bomb is released its forward travel will also be reduced by wind resistance, and it must therefore be released when the plane is closer to the target, than it would be if the plane was flying with the wind. Naturally when the wind speed is estimated and calculated, the altitude at which to fly is then determined. Or rather the best altitude at which to fly. In other words if it takes eight seconds for your bomb to drop from a bombing altitude of 1000 feet and your plane travels ground speed at the rate of two thousand feet in eight seconds, you must set your bomb sight so that the target will be in the “finder” (center of the sight) when you are two thousand feet away from the target. To sum it all up, you estimate wind speed and direction, then set your sight in accordance with the number of seconds it will take the bomb to drop from a stipulated altitude. Then you bomb from that altitude. And if you wipe out the objective, maybe we’ll give you a medal!

THE releasing of a bomb is simple. As the nose must drop first, the bomb is put in the rack, nose forward. It is gripped by what are called “toggles” at the nose and the tail. By pulling the toggle release, which is simply a lever in the cockpit with a wire leading down to the toggle catches, the catches are opened and the weight of the bomb itself makes it drop free. Some planes had individual bomb-racks under the wings. Each bomb could be released separately or all the whole works at once. The big bombers had vertical racks. In other words the bombs were placed one upon the other. When the lowest one was released, the one above it automatically dropped into the lowest one’s place.

Bombing by bombers and some observation ships was an art all its own. In pursuit ships bombing was a hit-and-miss affair. First, you oniy had about twenty pound bombs. Just enough for “surface” damage, such as in trench straffing. Second, you had no sights (though modern pursuit ships have bomb sights). And third, you often released your bombs on pursuit ships without any idea of hitting anything. That was, of course, when some enemy pursuit ships I jumped on you, and you wanted to reduce the weight of your ship, and thus increase its maneuverability qualities.

So there, Henry, you insulting buzzard, is some dope on bombs and bombing. And by the look in the C.O.’s eye I think he’s about set to drop an egg on your Uncle Wash-Out—so consider me gone!!

FROM the pages of the January 1933 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Top Man Wins… Maybe!

by Robert Sidney Bowen (Sky Fighters, January 1933)

WELL, I’ve had you upstarts under my wing for so long now that I guess I can’t call you fledglings any longer. Of course there are some of you who are worse than fledglings. But still some others of you have been paying attention, and have actually learned a thing or two about this business of war flying, and what have you. So from now on I’ll consider you all as promoted to the next grade, and call you buzzards. But, mind you, any cracks out of turn, or any funny business, and back you all go to the rank of fledgling. And take it from Uncle Wash-Out, there ain’t nothing lower in a pilot’s estimation than a fledgling. Okay, buzzard—here we go!

A few chinfests back (the C.O. of this mag will give you the exact date) I told you the hows and whys of Getting Your Hun. The main point I leaned on was the great amount of preparation before you even took your crate into the air. Well, this time I’m going to deal with technical points after you get upstairs and spot your man.

Now, read this over.

“Spandaus guns yammered savagely and twin streams of fire reached out for the Yank ship. But the pilot in that Yank plane was not to be caught napping. Slamming into a half roll, he immediately came out of it and zoomed up to cartwheel over and go plunging straight down on the German ship, his Vickers singing their song of death. It was all over then, for the Yank was top man, and top man always wins!”

Does that sound familiar? Sure it does! You’ve read something more or less like that in fifty different stories. But here is where I step into the picture and maybe make myself the nasty antipathy of a whole lot of your favorite authors. And maybe before I get through, the C.O. of this mag will toss me into the klink and get a greaseball to double for me. But, come what may, I’ve got to be honest with you buzzards. In these chinfests I’ve got to stick to the technical truth. In others words, I’ve got to be on the up-and-up. Now, don’t get the idea that I’m only trying to pick your stories apart. That’s not the idea. I’m just going to elaborate on points that your authors didn’t have time to enlarge upon. Their stuff is fiction—action—boom-boom stuff—and all the rest of it. But my stuff is straight stuff. Oh, maybe dry in spots, but the true dope.

Okay, lean on this. Top man in a scrap does not always win!

The method of getting an enemy ship depends upon a lot of things. The most important thing is what kind of a ship it is. In other words, you don’t go after two-seaters the the way you go after a pursuit ship. And you don’t go after a pursuit ship the way you go after a bomber. And you don’t go after any of them the way you go after a balloon.

Of course, there is one item that applies to them all. That is, getting the old machine-gun bullets in where they will do the most damage. But thinking about it and accomplishing it are two different things.

Now, for example, let’s take the case of two pursuit ships scrapping it out. Let us say that the Hun comes in from the east, and you come in from the west. You are both at the same altitude and you spot each other at the same time.

WELL, naturally, both of you will start to climb. The more altitude you have the more advantage you have. (Don’t forget, now, I’m talking about pursuit ships.) Why is altitude an advantage? Well, buzzards, as I’ve told you many times before, a pursuit ship pilot can only shoot his guns in one direction—forward. Therefore, he has no protection at the rear. It stands to reason, then, that the ship with the most altitude has the better chance of maneuvering down on the other’s tail, or as it is often called, his blind spot.

But in this case we’re talking about, we’ll say that neither you nor your enemy get greater altitude. You draw close together at the same level. Well, you both probably take nose to nose shots at each other. Scoring any damage that way is not common occurrence for the simple reason that you are both protected by a wall of metal. And that wall of metal is your engine. Also, a plane coming dead on to you presents a mighty small target. If you don’t think so, well, the next time you go up fly nose to nose with some other ship and take a good look for yourself. Fig. 1.

WELL, you can bring your enemy down by flying right into him. But that would mean curtains for you, too. And, besides, ten times out of ten, your enemy doesn’t want to cash in that way. So he pulls out of the way at the last minute. Usually he zooms up in a climbing turn, hoping to drop down on your tail. Well, you beat him to it and do the same thing yourself. And what’s the result? You have both gained altitude, and you have dropped into what the boys used to call the ring-around-rosey, or the tail chase tail formation.

Take a look at Fig. 2, and you’ll see what I mean. You both are on the outside of circle, headed in opposite directions, and chasing each other’s tail around in the air. Naturally, you both are trying to get around faster than the other so that you can plant a nice little telling burst in the other’s tail. But you find out that the other ship has just as much speed as you have, and the result is that you both stay on opposite sides of a big invisible circle.

All right, buzzards, I know what you’re going to ask. So sit down, and I’ll tell you. Why not shorten the diameter of your circle? In other words, why not bank more sharply? Well, it’s a swell idea if you can do it. And if you can, why of course you have a beautiful broadside shot at your enemy. But just remember that your enemy isn’t flying around and reading a copy of SKY FIGHTERS. Not by a long shot. If he’s a good pilot he’s trying to pull the same stunt on you!

WELL, of course you can’t keep on going around in a circle all the time. If you keep it up long enough you’ll both starve to death. So someone has to break the circle—bust up the ring-around-rosey idea. But whoever breaks it has got to be quick and careful. Once you pull out of it your opponent has a couple of precious seconds in which he can whip around and let you have it.

One of the best ways to do that (as proven in the late Big Fuss) was to pull up and over toward the inside of the ring. In other words, you try to climb up and come down on top of your man. His defense against that is to do the same thing himself (and bring both of you right back where you were) or else to whip over and down and then up. The idea being to get you from underneath before you can bring your guns down to train on him.

RIGHT there is a good example of what I said at the beginning. If your enemy should be successful in whipping down and up before you whipped up and down, why it would be a case of top man getting it in the neck.

In view of the fact that I’ve illustrated my top man idea I’ll end this scrap by saying that you catch him napping and shoot his pants off, and his life along with them. That, of course, is the final thing in every scrap—I mean, that one or the other pulls a surprise maneuver that catches the other napping and allows the chance for the killing burst.

But before I speak about observation ships, I want to point out another example of top man not winning. Suppose when you break the circle by zooming up and over and your enemy slams into a quick half-roll and dives away. Well, of course, he takes a chance that you may be able to slide around and get him. But he has a few precious seconds in which to get up a lot of diving speed, before you are in a position to dive after him. The result, of course, is that you are top man, but your enemy is diving away from you, putting air space between you and him, which means a longer range shot for you. And not only that—he presents a rotten target. He is edge on to the ground, and you’d be surprised how a ship diving away from you seems to melt in with things below on the ground. The ground is dark and the outline of parts of the ship presented to you are also dark. In other words, the ship forms no silhouette, like it would if there was a background of sky or clouds. To get the idea, look at Fig. 3.

And now for the two-seater ships.

YOU are patroling around and suddenly you see an enemy two-seater taking pictures behind the lines. Naughty! naughty! That pair of young men must be taught a very lasting lesson right pronto! So you go down after them. But do you drop down on their tail?

Well, if you do and they see you coming, you won’t need to worry any more about how you’re going to pay your losses in that poker game in the mess last night. And why? Well, buzzards, there is an observer in that two-seater, parked in the rear cockpit. And when he left his home drome he took along at least one, and probably two, guns mounted on a swivel mounting that enables him to shoot in any direction except forward and down. And you can bet your sweet life that he still has them with him. So, if you come piling down from the rear and he sees you, well, you’re just going to get a whole mouthful of bullets that won’t taste good.

OF COURSE, there is an exception to everything, and it is possible to pile down on an enemy two-seater from the rear, and pop it right out of the sky. But such a case is only when the occupants of that two-seater are napping, or are too busy doing something else, and therefore fail to see you before your bullets are slapping into them. Such an occurrence could happen, if you got the sun at your back. In that case its brilliance would blot you out of their sight.

But enough of what you shouldn’t do. Let’s get on with what you should do.

In this case we’ll say that it is not a surprise attack. The enemy sees you coming. Well, no matter what angle you come down from, you will be in their range of fire. And naturally you cannot come down to their level though out of range, and then bore in from the side, for the simple reason that a two-seater doesn’t have to go into any ring-around-rosey maneuver. It doesn’t, because the observer can train his guns on you while the pilot flies the ship dead ahead.

All right, buzzards, all right! I’m getting to it, so keep quiet.

The thing to do is to attack the two-seater in its blind spot. And the blind spot of a two-seater is the area underneath the ship, extending from the prop to the tail skid. Neither pilot nor observer can bring their guns to train on any part of that area. And so the idea is to dive down under the two-seater and come up at it from underneath. In other words, hang on your prop and plant your burst right smack through the floorboards of that two-seater. And no matter which way, he goes, you just try and keep in that blind spot. Fig. 4.

And so I murmur again—what do you mean, top man always wins?

Now for bombers. And are those babies tough! Present-day bombers, as you buzzards probably know, have about as many blind spots as a goldfish bowl. And the old wartime bombers didn’t have so many themselves. About the only blind area they presented to attacking planes was directly under the forward parts of the ship, and close up under the wings.

And so you won’t be misled, let me tell you that the best way to get one of those big babies was to take along a couple of your squadron pals with you. The idea being that while a couple of you worried the occupants of the bomber the rest would pile in from the side they weren’t looking at, and get in your shots. But should you be alone, the best way was to take your pot shots from underneath. Top man wins, eh? Oh, yeah?

NOW, before I rush myself away from you, I’ll just mention a word or two about top man and balloons. Getting a balloon is a job that really is ninety-nine and nine-tenths surprise. You have several factors against you. First, the men in the balloon are keeping a sharp eye out for you. Second, the ground defense of that bag is also keeping a sharp watch for you. Third, it is possible for the bag to be hauled down before you can close in on it. Fourth, you can be exposed to terrific fire from the ground. Therefore, the bigger the surprise, the better chance you have of getting the bag.

LET’S say you pile down on it, and miss. Meantime you are diving through lead hell—that lead hell doesn’t miss. Well, you may be top man, but it’s curtains, unless luck is with you and you can fly clear before you’re struck in a fatal spot.

Well, let’s attack another way. Fly close to the ground (making it hard for the men in the bag to spot you against the ground, and completely hidden from the bag’s ground forces), then at the last moment zoom up at it and let drive. Your shots go home and the bag goes blooey. It was top man, wasn’t it? And in the meantime you are top man to the ground forces, and they may nail you before you can zoom out of range. Fig. 5.

So, as I said at the beginning—it depends upon a lot of conditions and cirmustances whether the top man wins or loses. In most scraps it is favorable to be top man—but that rule does not hold good all of the time—and don’t let Santa Claus tell you that it does!

FROM the pages of the November 1932 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Konking Engines

by Robert Sidney Bowen (Sky Fighters, December 1932)

ALRIGHT, YOU FLEDGLINGS, sit up and pay attention! – Huh? What am I sore about? Well, I’m not exactly sore, just a little bit nettled, if you get what I mean. Its this way. A flatspinning fledgling out Arkansas way (I won’t mention his name) has sent me a letter that calls for a light in any country. Yup, its little short of an insult to all us wonderful war pilots.

He says in part:

    I have been reading air magazines for a long time, and although I enjoy the stories, particularly Air Fighters yarns, there is one thing that gives me a pain in the neck. Why, does the Hero always have his engine go blooey just when he’s all set to knock some Fokker out of the sky?
    Did you war pilots ever inspect your engines, or were you just too darn lazy? In other words, there were too many forced landings in the World War to suit me. I’ll bet I’d have kept the old crate going, if I had been over there!

Now I ask you, is that conceit, or is that conceit? However, in view of the fact that some of you other babes-in-wings have hinted at the same thing, I’m going to devote this meeting to konked engines, and how they got that way. If I get too technical, its just too bad for you. So button back your ears!

Before I start, though, I’ll stick in a word about forced landings in general. No pilot ever asked or prayed for one! And we’ve all had them. Right from me, the greatest, down to you, the poorest. A few years ago the papers were full of news about H.M. Prince of Wales falling off his horse. People began to get the idea that the Prince did not know how to ride, which was certainly the wrong idea. Mr. Will Rogers cleared that point up when he asked, “What’s the Prince going to do when his horse stumbles and falls, stay up there?” Well, that also goes for pilots with konked engines. What are they going to do? Walk around on the clouds while the ship glides down?

But to get real serious. Many forced landings during the late war were due to carelessness on the part of the pilot. But an equal number were just tough luck. We’ll pass over the carelessness part and just deal with the tough luck. In short, what were the things that made the old power plant give up?

All the answers to that would fill up this whole magazine a couple of times. So we’ll just deal with the major causes. Like in an automobile engine there are three important things in an airplane engine. The oiling system, the carburation system and the ignition system. All three are absolutely indispensable to the proper functioning of the engine, and the failure of any one of them will cause the other two to fold up.

Take the carburation system. The gas used during the war was usually the best that could be turned out. It was high test, AA, No.1, etc. But, the facilities for storing it at the squadron, often were not of the best. Careful as the pilot and mechanics might be, a few drops of water sometimes got into the gas tank. Eventually those drops of water got into the carburetor. Water being heavier than gas, they collected around the base of the needle valve and prevented gas from being sucked through into the cylinder head. Naturally, the engine stopped because it was gas starved.

Sometimes those drops of water didn’t get as far as the carburetor. They got stuck in a bend in the feed line—a bend that went upwards. The result was that the carburetor was blocked off from gas.

IN EITHER case, the line and the carburetor had to be blown free of water before the engine would hit on all six, or twelve. Now I’ll admit that sometimes the suction of your engine was great enough to suck the water clear, but lots of times it wasn’t. So you’d have to land and clear out the line on the ground.

And another thing. Air engines during the war, were comparatively speaking, mighty delicate pieces of machinery. Just let a few specks of dirt get in with the gas (all gas was strained into the tank as a precaution against that) and sure as the Lord made little apples, those specks of dirt would find their way into the carburetor and gum up the works. Most times they’d get under the needle valve seat, and keep it open, with the result that the carburetor would flood, and your engine would be gassed to death.

And one more thing about gas and carburetors. Vibration from violent maneuvering, to get the heck away from that Hun, would shake loose some of the feed line joints. The next thing you knew the raw gas would be spilling out into God’s open spaces, instead of into the carburetor. And I’m not even saying a word about a Spandaus bullet nicking a feed line, or puncturing your gas tank.

Now, take the oiling system. Most air engines during the war were oiled by what was known as the splash system. Your engine of today is oiled by force feed, or a combination of splash and force feed. In the war engines the big end bearing of the piston slapped down into a sump full of oil and splashed oil all over the place. Oil reached the parts missed by the splash by working its way by centrifugal force through hollowed out channels. Of course, with force feed, you have an oil pump working off the cam shaft, that pumps oil to all necessary parts of the engine. However, with the war engines the oiling system was often put on the blink just the way the gas system was. In other words, some dirt would lodge itself in one of those hollowed out channels, block off an important bearing, and cause said bearing to burn out, due to lack of lubrication. And it did not have to be actual dirt either. A little gob of crusted grease would do the trick. True, engine failure, due to the failing of the oiling system was not particularly common. At least not in my experience. However, it did happen. And nine times out of ten, all the care in the world would not have prevented it.

There’s one thing you fledglings sometimes forget. That is, that the war crates were built and flown eighteen to twenty years ago. In other words, the ships you toot around today, have incorporated in them almost twenty years of aeronautical progress.

Now don’t get me wrong. As I said at another meeting, I’m not trying to give you the impression that we war pilots were supermen, etc. I’m just trying to bring to light a few of the things we bucked up against when you fledglings were doing flat spins in your cribs.

AND now for some words about the ignition system. Believe it or not, eighty per cent of the troubles that happen to your automobile are due to the ignition. If you doubt that, ask the first automotive ignition specialist you meet. The same thing held true with air engines. In your car you have battery ignition. In the war crates you had magneto ignition. Of course you have to interrupt me, and ask why? Well, a battery is additional weight for one thing. And for another, there was no ignition battery during the war that could stand being tipped upside down without the electrolite (liquid content of a wet battery) spilling out.

Yes, I know, I know! There were dry batteries to be sure, and planes that had wireless sending sets used them. But, you cannot recharge a dry cell. And that would call for new batteries darn near every patrol. And that would be too expensive for any government, even though said government had decided not to pay their war debts!

NOW I could get so technical that you’d go ground looping, but I’ll spare you, and just deal with ignition troubles in general. The first, and a very common one—spark plugs quitting. In most cases it was due to the plugs getting carboned up. The gas used in war crates was, as I have told you, very high test. In other words, it ignited, and how! Now, if the rings in the piston are not so good, and the oil ring fails to wipe the cylinder walls clear of all excess oil on the downward stroke, that oil is going to be burned when the vaporized gas is ignited. The result, of course, is carbon that collects on the spark plug points. Presently the gap between the points is closed up with carbon and the plug stops firing. Of course one plug going out does not necessarily mean a forced landing. But it means a loss of maximum power and a ragged engine. I once had the actual experience of getting back home with three plugs quitting on me. But that was in a rotary engine, and the inertia of the revolving cylinders aided by the six other firing plugs (a 9-cylinder Bentely engine) enabled me to make the grade, thank goodness! However, in a stationary engine, more than one plug quitting means that you’ll have a forced landing, nine times out of ten.

Of course the major part of an ignition system is made up of wires. Each wire, naturally has a definite purpose, else it wouldn’t be used. Therefore, if any one of them gets loose, it stands to reason that something is going to happen And something does. Any spark plug wires that shake loose and hit against the engine block instantly short circuit the cylinder for which they were intended. And let the engine ground wire work loose and the whole system goes on the blink. Now, when I say ground wire, I don’t mean a wire leading to the ground, terra-firma in other words. All ignition systems have a definite course of travel for that invisible thing called electricity. In your car it starts from the battery and goes right through your engine and back to the battery again. The path of return is called the “Ground.” In other words it has got to get back where it started. The part of it that is spent is made up for by the generator. To be more definite, the current starts from the battery, is maintained by the generator which also shoots it back to recharge the battery again. In the airplane engine of the war days, the magneto functioned as the battery, and generator combined. It still does in a lot of today’s ships. If wet batteries are used they are used mostly for lighting in the cabin, etc. After all, a battery is added weight, and a magneto gives a hotter spark, so naturally, everything is in favor of magneto ignition in airplane engines, instead of battery ignition.

Now, of course, one could say that constant inspection of your engine and its various parts would go a long ways toward preventing any of the faults of which I have been talking, coming to pass. And to a certain extent, that is true. And it is also true that we inspected our ships before each patrol until we were blue in the face. But in those days all the little kinks had not been ironed out of engines, and their construction was not of the best, so things did happen. I don’t mean to say that we had forced landings every time we took off. Far from it. But we did have plenty. Some of us, more than our share, perhaps. But we never prayed for them, and we did everything possible to prevent them. However, Rome wasn’t built in a day, and neither was a perfect aero engine. Our experiences during the war were ground work for engineers to work upon. So the next time your hero gets a konked engine just as he’s going to blast that Fokker apart, just bear in mind that he hasn’t got a 1932 aero engine up there in the nose. Either that, or else the author forces the poor bird down so that he can be taken prisoner and later escapes with valuable information swiped right off the Kaiser’s desktop.

But anyway, keep on writing in your questions fledglings, because, after all, I don’t get really and truly nettled when you take cracks at us broken-down eagles who used to make three-point landings . . . upside down! Cheese it! . . . The C.O. of this magazine!

FROM the pages of the November 1932 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Tricky Ships

by Robert Sidney Bowen (Sky Fighters, November 1932)

POWERLESS to do a single thing about it, the members of the 23rd pursuits watched the lone Camel flatspinning down to total destruction. Its pilot was plainly visible, battling the controls. But his frantic efforts were to no avail. Seconds later the nose struck, flames leaped skyward, and another pilot was added to the long list of tricky ship victims. . . .

And that, fledglings, was the way more than one Hun-getter checked in his chips during the late war . . . a victim of a tricky ship, not Spandaus lead. Now, don’t go getting the idea that those lads were dumb pilots, else they wouldn’t have allowed their crates to throw them. That’s not the idea at all. More than a few crack pilots got into trouble with a tricky ship and lost the decision. What we are going to try and point out this meeting is that during the late war a peelot had to be a heads-up peelot for reasons other than those manufactured in Germany.

Present day ships are so well designed and constructed that you can almost go to sleep and let them fly on by themselves. They are steady as a rock even in pretty punk weather, and when anything does happen there is always the good old ’chute-pack on your back. All you have to do is step overboard, count six and pull the ring. But the war crates? Ah, there you have something different . . . mighty different, and don’t you forget it! In the first place, they were all designs of 1914-1918 vintage, naturally. Designers didn’t know as much then as they do now. And, there were no parachutes for pilots. The Germans started using ’chutes during the last year of the war, but the Yanks, English and French never had them except for balloon work.

That statement may surprise you, after some of the war-air yarns that you’ve been reading. But it happens to be a fact, and any war peelot will check on that statement.

But to get back to the business of these tricky ships. That questionasking fledgling over there in the corner looks like he’s ready to burst with curiosity, so I’ll talk fast and maybe choke him off.

JUST for the heck of it, we’ll take some of the war crates, one by one, and elaborate on their tricky features and peculiarities.

Of course, the Sopwith Camel is the first on the list. Of all the tricky ships that crossed over No-Man’s-Land the Camel was the trickiest of them all. A wonderful stunting crate, and great stuff in a dog scrap, but my, my, how you had to watch that baby and check its tendency to throw you for a flock of wooden kimonos!

The Camel was powered with a Clerget, Le Rhone, and later for high altitude work, with a 210 Bentely. All three were rotary engines. And all three gave the ship its nasty desire to flip over and down on right wing and into a tight spin. It was propeller torque that did that. As I explained at another meeting, propeller torque is a tendency for a ship to go in the opposite direction to the rotation of the propeller blades. In a Camel the prop rotated from right to left (standing in front of the prop). Therefore the ship would try to swing to the right (the pilot’s right when in the cockpit). Naturally, the way to counteract that was to keep on a bit of left rudder all the time. In other words, when you wanted to make a right bank you really eased up a bit on left rudder and let the torque carry you around, instead of actually putting on right rudder. The Camel was also rigged to whip around on a dime, and that helped the engine torque idea all the more. There was no dihedral on the top wings, but there was about two degrees on the bottom ones.

What’s that? What’s dihedral?

Well, Fledgling, dihedral of airplane wings is the angle of a wing upwards and outwards to the horizontal. In other words, if a wing is pefectly flat it has no dihedral, but if it tilts upwards it has. No dihedral reduces the horizontal stability of a plane, and in this way. The area under a tilted flat wing is the same on either side of the fuselage. But when there is dihedral the area (called horizontal equivalent) becomes increased on the down-tilted side and increased on the up-tilted side. Therefore the natural reaction is for the plane to right itself to an even keel.

Naturally the dihedral on the lower wings of a Camel was put there so that the ship wouldn’t fly completely wild, but still be a fast maneuvering ship. Never having experienced such a thing, I can’t go on record definitely, but I would say that flying a Camel with no dihedral on any of the wings would be just like going down a mountain road at midnight, with both headlights on the blink. You’d just hang on and pray that you didn’t hit anything.

WHENEVER a pilot slipped up in alertness and engine torque whipped a Camel over on its right wing, it always fell into a tight spin. Now a spin is nothing to get grayhaired about, even in a Camel, if you have altitude. BUT, the camel was so darn sensitive to the controls that when you took it out of a spin you had to be mighty careful lest it didn’t flip right over into a spin in the opposite direction. In case you don’t know, you stop a plane from spinning by moving the controls as though you wanted the ship to spin in the other direction. But as soon as the ship stopped spinning the original way, you checked its tendency to flop over on the opposite side, and began to get the nose up. In a Camel split-second checking was in order. You couldn’t take your time about it. The instant the ship stopped spinning you had to check and get the nose up, else you went spinning down in the opposite direction, and had the whole darn job to do all over again.

THERE was also another tricky feature of the Camel, and one which cost many lives. That was the tendency of the ship to go past the vertical when diving.

You would start a steep dive in a Camel and unless you watched the ship the nose would start to swing back to the rear, and before you knew it you were diving backwards as though you were going to pull an outside loop. The way to get out of that was to pull the stick back so that the nose would start moving forward, and then when you got vertical again to slowly ease the nose up. But it was right at that moment when a lot of chaps checked out of the world, and for this reason. When a Camel’s nose starts back toward the vertical, after being past it, it comes slowly at first but as it reaches the vertical it develops a vicious tendency to whip upward in a zoom. If you don’t check that and hold the ship steady in a vertical dive, and ease up slowly, why, the result is that you lose your wings. The savage up-thrust of the plane, with the top surfaces of the ship broadside to the line of motion, just wipes the wings off as though they were so much paper.

Now, if you’ve been listening to me, instead of falling asleep like that fledgling over there, why, you’ll realize that both of the principal tricky features of a Camel can be hooked up together. But, in case you don’t, it’s like this. You’re buzzing along, and start to make a right bank, a split-arc turn. You take off too much left rudder, and zowie, engine torque whips you over to the right and into a spin. You start to take it out, don’t check it in time and zowie, it flops over into an opposite spin. You start to take it out, check it this time, but before you realize it you’re diving past the vertical before you’ve had time to start getting the nose up. Well, you try to get the nose forward to the vertical, and then when it gets to the vertical you don’t hold it steady. Zowie the plane zooms up, the wings come off, and zowie . . . no more peeloting for you in this world! Now, do you get the idea?

ANOTHER tricky ship that Sopwith also made was the Sopwith Pup. Strictly speaking, it wasn’t what you’d call a dangerous ship. It was simply a crate that made you stay awake if you cared anything about seeing the girl friend again. It was a very small job, and naturally very light. And being light, it floated like a feather. And as it floated like a feather, the job of landing was just that much more difficult. Time and time again (until you got the hang of things) a greenhorn pilot would overshoot the field. Of course that’s okay provided the engine is still functioning. You simply feed it the hop, go around and try again. But in the event of a forced landing, why, the story was different. You only had one chance then, and if you didn’t make good you were just out of luck. The Pup came out before the Camel but was used mostly for training purposes. It was so small and light that it couldn’t stand the gaff in a dog-scrap.

In the early part of 1918 the Sopwith outfit came out with a ship called the Snipe. It was an improvement on the Camel, and was intended for high altitude work. Only two Snipe squadrons got out to France before the Armistice, and those only for a few weeks. But they certainly knocked the pants off the Fokkers, which proves what swell ships they were. The first model was known as the Unmodified Snipe. It was the tricky job. The fuselage was barrel shaped and the rudder and tail surfaces a bit too small. The result was that when you got into a spin it was the task of your life-time to get it out. The reason for that was this. The fuselage being so big and the tail surfaces so small, the slip-stream didn’t strike all of the surfaces. When the ship went into a spin an air-lock would be formed between the rudder and the elevators. That would practically render the controls useless. In other words the tail surfaces were so blanketed by the size of the fuselage that they wouldn’t get the proper grip on the air. (Fig. 2.) Once the ship got into a spin it was difficult to present a flat spin developing when you tried to take it out. It was practically impossible to come out of a flat spin. What you had to do was go back into a tight spin again and make another try to get past the flat spinning point. Just so’s you won’t be too confused about my jabbering, a tight spin is when the wings revolve about the fuselage as the axis. And a flat spin is when the plane pivots around the nose in a gyroscopic motion. In other words, the plane is at a slight angle to the vertical and the whole plane goes swinging around in a circle, sidewise.

Yeah, no fooling, a spin in an Unmodified Snipe was not so hot. We speak from experience about that item. One day during a joyhop we slipped into a spin at ten thousand feet, and it took us just eight thousand feet to get out of it. Another two thousand feet and yours truly wouldn’t be here chinning with you fledglings.

Later that fault was corrected in what was called the Modified Snipe. The elevators were made a bit bigger and the ship had a balanced rudder and balanced ailerons. And if you don’t know what those things are, why, just take a look at Fig. 3.

THE well known Spad might be called a tricky ship because it was more or less a flying brick, and didn’t have much of a gliding angle. Naturally, all that means that the Spad was heavy, and it was, darned heavy in proportion to the wing surface. Under full power it was a sweet ship, but when you cut the gun you had to look out. The nose just plopped right down and you started diving hellbent. In the event of a forced landing you had to decide on your field mighty quick, because you didn’t have much time to think it over. You just naturally lost ground too fast. We once had a Spad forced landing. The engine konked at two thousand feet and we were just able to make two and one-half gliding turns to get into a field. But, of course, maybe a GOOD pilot could have made five. Now, you know what we think of us!

Speaking of landing reminds me of the Sopwith Dolphin, a high altitude scout that came out in 1918. The cockpit was right under the top wing. In fact we got into it through an opening in the wing. It was a smooth job until it came time to land . . . then, hold her Newt! If you ground looped it was just too bad. Why? Well, you usually went over on your back, and there you were, head down in the cockpit and no way to get out because the opening in the top wing was right smack against the ground. And if the ship caught fire . . . well, you can figure that out for yourself! After several chaps got burned alive or had their necks broken, braces were put on the top wing so as to give the peelot exit room when he needed it.

A LOT of your heros in this mag fly the good old S.E.5 and S.E.5a, but we can’t list either as a tricky ship, because it was only tricky when the peelot was just plane dumb. We mean this. The S.E. had what was known as an adjustable tail plane. In other words, from the cockpit you could adjust the tail plane (section to which the elevators are attached), so that it would tilt up or down. In other words, you could make the ship nose heavy or tail heavy, just as you wished. When taking off you would tilt the tail plane upward and that would help you get into the air sooner. And in landing you’d do the same thing because the reaction would be for the nose to go up, and thus you would have less trouble getting the tail down for a nice three point landing. But when you forgot about that tail-plane the ship got real tricky. For instance, you might pile into an S.E., slam home the juice and go tearing across the field. If the tail-plane happened to be tilted down you’d probably dig your prop into the ground. Another case is when you’re landing and over-shoot the field. Well, you feed the hop to go around again, and pull back the stick to get more altitude. Well, if the tail plane has been tilted up, as it should be for a landing, why, you’ll just go zooming up quicker than you expected, and if you don’t re-adjust the tail plane you’ll find yourself on your back at a rather low altitude for that sort of thing. So, of course, S.E. peelots remembered that they had a tail-plane just like they remembered they had an engine in the nose!

WELL, here comes that hard-boiled C.O. of this mag, and the look in his eye says, scram. But before I do, just let me lip another word or two. Don’t get the idea that we bohunks who flew the war crates were supermen. Far from it, believe you, me! But some of the ships were tricky, as I’ve been explaining, and the war peelot who went to sleep on the job, or didn’t keep his mind on the race, was asking for a lot of trouble that wasn’t German-made, either. But even a dumb peelot could handle them okay, if he paid attention to his knitting. And the very fact that we used to fly them, and are still alive, proves the above statement beyond all possible argument.

And the same to you! S’long!

FROM the pages of the October 1932 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Getting Your Hun

by Robert Sidney Bowen (Sky Fighters, October 1932)

PETE BANKS, of the 65th Pursuits, flashed into a screaming half roll, and went thundering down to pour burst after burst into the checkered Fokker. . . .

And then the story goes on to tell how Pete finally got his Fokker and returned home to be made round-shouldered by all the medals they pinned on him. But, if the truth be known, Pete, I wouldn’t pin a medal on you. Sure, I’d tell you that you were a swell guy for getting that Hun. And then I’d turn around and ask you why you wasted so much costly ammunition. Huh? What’s that? Oh, it was just that way in the story. Well, then I guess that it would be a pretty good idea if we told these fledglings here a little about the technical side of getting Huns.

Now, just so’s we’ll get off on the right foot we’ll make this statement. In the final analysis the only thing that really counts is getting your Hun. If you can bring him down by tossing tomatoes at him, why so much the better. But during the late war the recognized method was shooting them down with nice stinging bullets. However, there are ways and ways to get an enemy ship.

And, believe it or not, you do a big part of the job of getting an enemy ship before you leave the ground. What’s that? Why, you ask? Well, give me time to tell you about it. Just sit still, and don’t be fussing around so much.

Now let us say that we are flying an S.E.5a, powered with a 210 hp. Hisso-Viper engine. On that kind of ship we’d have two Vickers guns mounted on the engine cowling and geared to shoot between the revolving propeller blades. And, mounted on the top center section, we’d have a single Lewis gun that fired over the top of the propeller blades. Now, right here I want to put in a word about that Lewis gun. The Lewis machine gun, which was an aerial adaptation of the regular infantry machine gun, was never geared to fire between the propeller blades. It just couldn’t be done, for technical reasons we won’t take time to mention here. So if you ever read in a story where it was done, why you can just put it down that the author was thinking about the Vickers gun when he was writing the yarn.

Okay, let’s get on. We have three guns, a Lewis and two Vickers. The Lewis is fed by a drum that contains ninety-seven rounds. And the Vickers are fed by belts that contain a varying number of rounds. The usual number carried was about six hundred rounds in each belt. Now for the two Vickers that would make a total of around twelve hundred rounds. And on the Lewis there would be a drum of ninety-seven rounds. And in containers in the cockpit the pilot would carry two extra drums. So the total number of shots that the pilot could wham at a Hun plane was around fifteen hundred.

Whether you think so or not, the Vickers guns were finished for the day once the belts were run through. And that was for the simple reason that you didn’t carry extra belts. But, when a drum of bullets on the Lewis gun were used up, why, you could take off the empty drum and take one of the spare full drums and stick it on. Doing that was a simple job yet you had to watch yourself, else the drum would go sailing back over the tail plane. Here’s how you did it. The Lewis was mounted so that the end of the barrel slipped down into a snap catch. When that snap catch was released (by pulling a wire that lead down into the cockpit) the gun would tilt back on its mounting to a forty-five degree angle. In other words, the rear end of the gun would tilt down toward you sitting in the cockpit. In that way you could reach the drum with your hand. First you stuck your hand up and slipped four fingers under the leather handle in the center of the top of the drum. Then with your thumb you pressed a little sliding catch at the bottom of one side of the handle. Doing that, released the drum from the post it’s mounted on. And then you lifted the drum clear of the post and brought it back toward you, being careful to keep the front part of the drum tilted toward the prop wash. If you didn’t the wind would get under the underneath part of the drum and force the drum and your arm back and the drum would go sailing away.

BUT we got the empty drum off alright, so we’ll grab up one of the full drums in the cockpit container and put it back on the gun by simply reversing the operation. In other words, tilt it toward the prop wash, fit it down over the post and release the catch. Then we load the gun by pulling back the loading handle on the side of the gun. And then we shove up the rear of the gun so that the end of the barrel slips down into the snap catch. And then she’s all set to fire ninety-seven more rounds.

Well, so much for that. But let’s go back to where we haven’t loaded the guns. We’re still on the ground, and in the armament hut checking our guns to make sure that everything is in good working order. Now what we’ll do is load the belts and the drums. On the table in front of us we have a pile of regular bullets, a pile of tracer bullets, and a pile of incendiary bullets. And right close to us we have a dummy gun barrel. We load the belts in this order. First a regular bullet, then a tracer bullet, and then an incendiary bullet. And so on in that order until the belts and the drums are full. But let me say right here that every pilot had different ideas about what kind of bullets he’d carry. Some loaded two regular to one tracer and so forth. And of course if you were going after balloons you’d put in lots of explosive bullets. But before you put in any bullet, regardless of what kind it was, you’d first fit it into the dummy barrel to make sure that it would fit. In short, you personally inspected every single round that you intended to fire at some Hun ship. You might think that that was a waste of time, if you had a good armament officer. But, don’t forget, those little bullets and your little ship were the difference between life and death for you. So naturally you personally looked over everything, just in case.

Well, let’s say that the guns are loaded, the ship inspected, and that you are sailing over Hunland in quest of another bird for your bag.

Ah, you spot a dark speck off to the left and on the same level as you. You squint at it a moment and by knowing the silhouettes of German ships you can tell what type it is. This time it’s a Fokker. So you start to climb because in a dog fight the top man has the advantage. Why? Well, because a pursuit job can only fire one way . . . straight forward. Therefore his blind spot is his tail. And if you are above him it’s a darn sight easier to drop down on his tail than it is to try and climb up to it, for the simple reason that while you’re climbing up, he’s dropping down on you.

Well, for the sake of this chin-fest let’s say that you get above him a few hundred feet or so. He spots you coming and tries to get away. Now you’re all set to dive down on his tail and fire. You slide your fingers up to the gun release levers on the joystick and maneuver your ship until you get him in your sights.

And we’ll stop right there for a second while we talk about the gun sights.

There were two kinds of sights used. (See Sept. “Sky Fighters.”) One was called the telescopic sight, and the other the right sight. The telescopic sight was a tube about twelve inches long mounted parallel to the two Vickers guns. At one end it had the ring sight markings on the lens so that you sighted the same as you would if using the regular ring sight. Now, the ring sight was in two parts, the ring and the bead. The ring part was a metal ring about three inches across mounted on a post at the rear of the gun. The post continued into the ring to form a quarter inch ring in the center. And mounted on end of the barrel of the gun was a post that tapered up into a red colored bead.

What was that? What do you mean mounted on the gun? Good boy, I wondered if you’d trip me up on that. When you use only one gun the sights are mounted on that gun, usually. But when you use two guns, as we have in this case, the sights are mounted between the guns.

But about that ring sight. When you sight so that the red bead forward is square in the quarter inch ring at the rear it means that your guns (the Lewis included) are aimed at everything that that red bead is on. Now, you have three paths of fire, the two Vickers and the Lewis. Naturally you want those three paths of fire to converge at a certain point. The point determined upon is dependent upon the whims of the pilot. But the average distance is about two hundred yards from the nose of the plane. And so the guns are tilted or moved sidewise to effect that range. That is done on the ground of course, and the guns fastened securely in the desired position.

Alright, alright, I’m coming to it. What about the large ring? Well, here’s the idea of that. The average war plane had a speed of about 100 m.p.h. Now, let us say that a Hun ship is flying across your sights. If you waited until the red bead was on him and then fired, why, he would be past your bullets by the time they reached him. But if you fired when the outer ring was cutting his cockpit, why, he and the bullets would meet. In other words, the outer ring enabled you to take care of what was termed deflection . . . his speed against the speed of your bullets and the distance they have to travel. Naturally, pilot judgment has to be put into play in every case. But as a sort of standard gauge the ring sight is set so that a ship crossing your path two hundred yards distant will reach the center of the ring at the same time as your bullets, provided you fire when the outer ring is cutting the enemy’s cockpit.

Of course that is assuming that the Hun ship is flying at right angles to you. If he is diving down past the front of you his speed is greater. Therefore you would open fire when he was outside the ring to make sure that he dived into your burst of shots. And if he was climbing up in front of you, his speed would be slower. Therefore you would let him get inside the ring before you opened fire.

In other words, you really look through a ring at the enemy ship and open fire when he has reached the correct spot in that ring. And naturally you place him in the ring, outside it, or on it, as the case may be, so that he is headed toward the center.

A little while back I mentioned about the telescopic sight having the ring sight markings. Well, that’s just what I meant. Marked on the rear lens of the telescopic sight is the ring sight. So you use the telescopic sight just the same way.

Now, naturally, if you took out time to get your Hun this way or that in your sights, he might fool you and keep you chasing around the air all day long. In a scrap you can’t be accurate about that. You take a snap sight and fire, and your tracer bullets (which leave a tiny trail of phosphorous smoke) will give you an idea of where your other shots are going. But tracers start to go cockeyed after about two hundred yards of travel, so that is why the average effective range is about two hundred yards. Beyond that point your tracer bullets aren’t worth a darn. They burn as they go through the air and after a while their path of travel ceases to be straight.

AND now let’s get back to this Fokker we’re after. We start down in a dive and fire . . . and miss. The Fokker skids out of the line of fire. So we follow him around and let drive every time we get him in our sights. And of course all the time we are trying to stick on his tail . . . above him and behind him. But, we do not let our guns keep firing all the time. Our guns will fire about six hundred rounds a minute. So when you figure that out, if we fire for a minute steady we are all out of shots, with exception, of course, of our two extra Lewis drums of ninety-seven rounds each. But we haven’t had time to change the drums, because that’s a tough job to do when you are twisting around in a scrap and making sure that friend Hun doesn’t get on your tail.

So, naturally, we scrap with the idea of making every round count. Of course, every round doesn’t count. But we work that way nevertheless. And so we fire short bursts of, say, ten or twenty rounds at a time. But the idea of Pete Bank pouring burst after burst into that checkered Fokker is out! If he does that he’s wasting shots because if the checkered Fokker is in his sights, one burst will probably do the trick. And if it doesn’t, it means that Pete is just shooting cockeyed.

Now, don’t get the idea that bullet economy was the sole watchword of war pilots. It wasn’t. Yet, at the same time every pilot knew just how many rounds he had to fire. Some did act like Pete Banks, and go crazy and let the whole works go. But the great majority didn’t shoot until they were darn sure they had something to shoot at. And to make as certain as possible that they were going to hit what they shot at, they used the old sights just as much as they could.

When you think it over it really doesn’t take much to send a plane swirling down out of the sky. One little incendiary bullet in the gas tank will do the trick. Or one little bullet right in the skull of your enemy will do it too. Or a nice little burst of ten or a dozen that riddles the engine, or splits the prop will get desired results also. It’s all a combination of marksmanship and flying ability. Some of the greatest aces in the World War were terrible pilots, but they were perfect shots. They could knock the whiskers off a Hun at any distance, and that’s what counted. The Hun might outfly them, but once they got in just one crack, it was all over for the other fellow.

And I guess that it’s all over for us, for the present.

FROM the pages of the September 1932 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

Take-Off Chin Music

by Robert Sidney Bowen (Sky Fighters, September 1932)

“CHUCK” SEAVER, two fisted Skipper of the 56th Pursuits, legged into the cockpit of his Camel, rammed the throttle open wide, and went thundering across the drome to zoom up over the bordering trees. . . .

How many times have you read that in a yarn? Sure, plenty! But how many times have you actually seen it done in real life? You’re right, never! What’s that? . . . why not? Well, listen, Fledgling, next time the old man lets you take the car out for a spin, just shift into low and jam the accelerator all the way to the floorboards and see what happens! Sure, if you don’t tear the gears out, the car will stall on you anyway. Of course there are no transmission gears on a plane, but to shoot a full load of hop to an airplane engine from a standing start would cause it to konk out every time.

And, as a matter of fact, there were several things for Chuck to do before he took off. What about revving up his engine to see that the oil and engine temperature was okay? What about signaling to the grease-balls to pull the chocks away from in front of the wheels? And what about taking a look at the wind-sock to see which direction was correct for a take off? And what about a lot of things?

But that’s the idea of this month’s meeting. That question-asking Fledgling is here again, and he’s just loaded up to the eyes with questions. He shot ’em along to me air-mail, and I’ve got ’em all here. What he wants to know is all about the trick hobbies, hunches and superstitions, etc., of pilots during the war. And as a lot of you other clucks asked the same thing, I suppose I might just as well begin my chin-music right here and now.

Of course I can only give you some of the high points. If I were to chin about all the idiosyncrasies of pilots, I’d be chinning until the next Armistice. War pilots, you know, were a funny breed, so you’ll have to take it or leave it.

But to get started, let’s begin with a peelot having coffee, and maybe a small shot of cognac in the mess before taking off on a dawn patrol.

Well, it’s time to go, so he wanders out to his ship on the line. The mecs have got the engine started, and the prop is ticking over nice and easy like. Our peelot has on his Sidcot suit. You know, one of them teddy-bear things all lined with wool. If it’s winter he’s probably wearing knee-high, rubber-soled sheep skin boots. And may be he’s got a scarf wrapped around his neck. And if he’s going to do a high patrol he’s wearing silk gloves under his leather flying gloves. Real silk gloves (like Mother wears to the theatre) are about the warmest-things there are for the hands. Maybe he’s got his helmet and goggles on, or maybe he’s carrying them in his hand.

And so he gets to his ship. First he takes a look at the elevator and rudder wires just to make sure they’re okay. A friend of mine in France used to spit over the rudder for good luck after he’d finished such an examination. Then the peelot puts on his helmet and goggles and makes sure the helmet strap is fastened nice and snug. And then he climbs aboard, and fastens the safety belt. Some pilots used just the regular safety belt that went around the waist. But others also used safety belts that went up over the shoulders. The idea was so that they would be held in the seat, and their eyes still on a level with the gun sight, when they went over on their backs in a scrap.

OF COURSE, before the pilot left the mess he made sure that he did not have any papers or things in his pockets that would be of value to the enemy in case he was forced down and taken prisoner. But to make doubly sure, a non-com goes to every pilot sitting in his plane and asks him if he has forgotten to look through his pockets.

And now that the peelot is seated in the ship, he takes a look to make sure that his ammo belts are fed into his Vickers gun in okay style. Then he grabs the loading handle (often called cocking handle) and loads the guns. If he has a Lewis on the top wing (when flying an old S.E. 5), he makes sure that it is loaded. And then he pulls up the handle of the oil reservoir of his gun gear (see July issue of SKY FIGHTERS). The idea of that, of course, is to build up pressure in the secondary pipe line so that his guns will fire when he presses the trigger trips on his joystick.

Now, some pilots used to use the well known ring sight for aiming, while others used what was known as the telescopic sight. A long telescope, maybe twelve or fifteen inches, mounted right between the guns. The guns are set to converge with it, according to the likes of the pilot. By that I mean that some pilots want their bullets to meet with the line of sight at one hundred yards, some one hundred and fifty, and some two hundred yards, etc. It all depends upon the wishes of the pilot in question.

What’s that? What am I talking about? Well, listen. You have a gun mounted on the right side of the engine cowling. And you have a gun mounted on the left. Now naturally you want those two paths of bullets to come together at a certain point so that there will be one big burst going into your target. And so the left gun is pointed a bit to the right, and the right gun is pointed a bit to the left. And the ring sight or telescopic sight is set right in the middle between the two. Now, the distance from the muzzles of the guns that you want those two paths of bullets to meet is simply regulated by the amount you set your guns to the left or right, as the case may be. Now don’t get the idea that the guns are re-set for every flight. When the pilot first gets his plane and tests it out, he has the guns mounted the way he wants them, and then they stay that way. Now do you get the idea?

BUT to get back to this telescopic sight. When the plane is on the ground, there is a little leather cup that can be fitted over the two ends of the telescopic sight so that the lenses will be kept clean. Of course the pilot takes them off. Sometimes only the rear lens is covered.) And then, to make sure the lens is all nice and polished, the pilot takes a silk stocking tied to the top of his flying helmet and polishes the lens.

Oh? So you thought war peelots used to tie a silk stocking to the top of their helmets just to look trick, eh? Well, maybe that was part of the idea. But that silk stocking came in plenty useful many times. One use was to clean the telescopic sight lens, as I just related. But the main use was to wipe off your goggles when they got spattered up with oil when you were in the air. In other words, it was just a handy cleaning rag always within reach because it was trailing off the top of your helmet.

What’s that? Where did war pee-lots get silk stockings? Now listen, Fledgling! They bought them in a store. Or maybe a peelot’s sister sent him one of her old ones in a Xmas box. Or maybe . . . well, never mind. You’ll find out soon enough in the next war!!

And now the peelot is fastened in, his guns are okay, and the telescopic sight is cleaned, and the handle of the oil reservoir has been pulled up. So next he moves the rudder bar and waggles the stick just to make sure that there isn’t any slack in the controls that has developed over night.

Then he signals to the waiting mechanics. A couple of them brace themselves against the leading edge of both the right and left lower wings. A third drapes himself over the fuselage just where it is joined by the tale plane. And the peelot pulls the stick all the way back to get the elevators tilted up as far as they will go. Of course the chocks are still in front of the wheels. Then the pilot eases the throttle forward slowly until the engine is roaring full out. And as he does that he looks at his various instruments to see that everything is functioning in proper style. He just lets the engine roar full out for say half a minute, and then pulls the throttle back.

NOW he is set to take off. (Of course we assume that his instruments showed everything to be okay when he revved up the engine.)

If it is a Flight patrol, the leader goes first. Then the next in rank, and then the next, and the next, and so forth. Sometimes they all taxied out to formation position on the field and took off together. But most times the field was too small for that, and they took off one at a time, and formed formation at a certain pre-determined height above the field, or a nearby village.

But we’ll let this peelot we’re chinning about take off by himself.

The grease ball who has been draping his manly form over the tail moves himself, and the pilot waves his hand in a left to right motion. That means . . . pull the chocks away. The mechanics do that, and then, if the plane is already headed in a correct take-off position (into the wind), the pilot gives the grease balls a chance to step clear and then pushes the throttle forward slowly and pushes the stick forward to get his tail up . . . and away he goes. Now, if he isn’t headed into the wind he taxies out, with the help of the grease balls hanging onto the wings, and swings around into a correct takeoff position. But don’t let fiction story writers kid you . . . the peelot doesn’t slam his throttle home! He eases it forward and gives the engine a chance to pick up full revs without tearing itself apart.

And, incidentally, the pilot seldom takes off right from the hangar line. Even if the wind is blowing toward him, he taxies out a bit. Why? Well, because an open hangar is right behind him, and when he takes off he blows half the drome right back into that hangar and all over any planes that might be there. And when he does that, why the C.O. usually has seventeen fits and chews his ear off when he gets back.

Yes, yes, I know, I know . . . you want to hear about hunches and hobbies, etc. Well, the C.O. of this mag is handing me some mighty tough looks. Guess he wants to get a word in about something that is interesting, so I’ll have to make it short.

The first is . . . the old superstition about lighting three cigarettes on a match. Bunk! But we used to like to live up to it just for the heck of it. Some other war peelot may call me a liar for that crack . . . but it really was just a superstition we liked to follow. It originally started in the Boer war. The English Tommies were short of matches, so several of them used to light their pipes on the same match. For no reason at all the Boer snipers opposite them used to try and pick off the third guy who lighted his pipe. And that’s how it came to be an omen of tough luck when a soldier took the third light off a match.

Sometimes you used to get hunches that it wasn’t so hot to fly on a particular day. Most times you just lived it down and went ahead with the job to be done. I got a hunch like that once and went just the same. Well, the engine konked out, a skyful of smoke belched out of the engine cowling, and I forced landed and wrapped myself around a tree. Well, was it because of the hunch? It was . . .but in this way. I didn’t want to fly that day, so I was looking for trouble . . . all nerved up, and all that sort of thing. And when you get that way, something usually does happen, believe you me.

A pal of mine once got a no-flying hunch on a day in training school when he had to take a test in target shooting. He was all goose pimples about it, and asked me to double for him. Well, it wasn’t an important test (no instructor around to watch), so I said, “Sure.” And I went up and shot off the rounds for him. When the score of hits was checked, and his instructor got hold of it, said instructor bawled the pants off him for being such a lousy marksman. So that gives you an idea of how good I was.

All right, C.O., all right . . . just a few more words. And they are about mascots, or lucky pieces, pilots used to carry. The famous ones were the two little French wool dolls, Nanette and Babbette. And of course there was the face of the girl-friend stuck on the crystal of your wrist watch. And maybe, if you were brave at some time, a pretty little pink garter, or maybe a stuffed teddy bear, or a monkey, or a doll, or most anything that you could lay your hands on. In other words, pilots used to go visiting and bring back anything that wasn’t nailed down and use them as luck charms.

And of course, there . . . ouch! See you again, Fledgling! The C.O.’s got my shirt tail, and pulling hard. S’long!

FROM the pages of the July 1932 number of Sky Fighters:

Editor’s Note: We feel that this magazine has been exceedingly fortunate in securing R. Sidney Bowen to conduct a technical department each month. It is Mr. Bowen’s idea to tell us the underlying principles and facts concerning expressions and ideas of air-war terminology. Each month he will enlarge upon some particular statement in the stories of this magazine. Mr. Bowen is qualified for this work, not only because he was a war pilot of the Royal Air Force, but also because he has been the editor of one of the foremost technical journals of aviation.

The Constaninesco Interrupter Gear

by Robert Sidney Bowen (Sky Fighters, July 1932)

ALEC WATSON, leading Hun getter of the 23rd Pursuits, crouched over the stick, glued his eye to the ring-sight, and tripped the triggers. . . .

Now just a second, Alec old sky eagle! What do you mean, tripped the triggers? Generally speaking, that is correct. But technically speaking it is not so correct. You, personally, Alec, do not trip the triggers. Of course, being an A1 Hun getter, you realize that. But there are a lot of fledglings around here who don’t. So I think it would be a pretty good idea if we went into this question of tripping triggers, and found out just what it was all about.

Alright, fledglings, gather ’round, and let’s go!

The pilot of any pursuit plane used in the great war, could only shoot in one direction . . . that was forward. Sometimes he had one Vickers gun mounted on the engine cowling, and one Lewis mounted on the top center section. Sometimes he had two Vickers and one Lewis. And sometimes he had just two Vickers. But regardless of what he had in the way of guns, they were always mounted on something and pointing straight forward. We’ll just forget about the Lewis gun because that was mounted on the top center section and therefore was able to fire clear of the top peak of the propeller disc. Now when I say propeller disc I simply mean the circle inscribed by the revolving propeller.

But, the Vickers gun being mounted on the engine cowling, just forward of the pilot’s cockpit, must fire through the prop disc, if it’s going to fire at all.

I just heard some one ask: “What about hitting the revolving propeller blades?”

Well, fledgling, that’s just what I’m getting at. We don’t want to hit the prop blades, do we? I’ll say we don’t! So some way we’ve got to work things so that the shots from our gun will pass between the prop blades on their way to that Hun johnnie sitting up there in the sky.

And here is how we do that little thing.

As a matter of fact, it has already been done for us. A gentleman by the name of Constaninesco invented what was known as the Constaninesco Interrupter Gear. It was composed of four parts. 1. The generator. 2. The trigger motor. 3. The reservoir with Bowden control. 4. Pipe lines, main and secondary.

The generator is simply a small* cylinder affair with plunger attached, which is mounted forward on the engine, and in a vertical position. The drive for the generator is generally taken (on stationary engines) from the boss of the propeller by means of gears which engage with a cam shaft leading to the vertical generator. To put it another way, the generator is just a small cylinder with a plunger at the top which is forced down every time the revolving cam on the cam shaft strikes it. And that cam shaft is not the cam shaft of the engine itself, but a separate cam shaft which is revolved by means of gears which attach it to the boss of the propeller. And, of course, when I say boss, I mean the metal plates and bolts which hold the propeller on the crankshaft of the engine.

Now, the next thing is the trigger motor, as it was called. As you all probably know, the Vickers gun operates (briefly) by, what is cabled, the lock moving forward and backward inside the gun. The lock is about three inches by four inches and maybe an inch or so thick, and contains all the trigger mechanism of the gun. Now, one of its actions as it moves forward in the gun is to cock the trigger which is a part of it. Then as it rides back again in the gun the trigger, which projects up out of the top a bit hits against a movable pin fitted at the rear of the gun casing. And of course that action trips the trigger and the gun fires.

IT IS that movable pin that I’m yarning about now. It is simply a round slender piece of metal which projects out of the rear end of the gun and is fastened to a thumb lever. In other words, when firing a Vickers on the ground you simply grip the spade handles of the gun and press your thumbs against the thumb levers. That forces the pin forward so that the end of it trips the trigger as the lock slides back. Now, when you don’t press the gun naturally doesn’t fire because the pin, which is really like a plunger on a spring, is forced back by the spring action so that the trigger doesn’t touch it as the lock slides back.

Now, what we’ve got to do is attach something to the rear end of that pin to take the place of the thumb levers. The reason being, that running from our generator up front to the pin at the rear of the gun is a length of quarter inch copper tubing which is filled with oil. Ah, you’re guessing it already. That’s right . . . as the cam rotates and strikes the plunger in the generator it sends a pulsation back along the copper pipe full of oil and forces forward the pin in the rear of the gun so that it trips the trigger of the lock. So what we really do is fit another plunger to the rear of the gun to take the place of the pin with its thumb levers.

Now, so far, we have a plunger at the forward end of the copper tubing, and another plunger at the rear end. The forward plunger is set so that the revolving cam will hit it. And the rear plunger is set so that as a pulsation of oil forces it forward it will trip the trigger lock.

Just oil (nine parts parafine and one part BB vacuum oil in the copper tubing isn’t going to do us any good unless we put that oil under pressure. So we use what is called the reservoir. The reservoir is something like a double bicycle pump. In other words, a plunger and chamber inside of a larger chamber. At the end of the inner chamber there is a copper pipe-line running to the one we’ve just been talking about. Just so we won’t get too mixed up, the copper tube running from the generator to the trigger motor is called the main pipe-line. And the tube running from the reservoir to the main pipe-line is called the secondary pipeline.

Now, the plunger in the inner chamber of the reservoir is attached to a handle at the top, and there is a strong spring around the stem of the plunger to keep it forced down. In other words, when the handle of the plunger is pulled up and released the spring tries to force it down. And of course the reservoir is attached to the inner right side of the cockpit, at an angle of forty-five degrees, so that the pilot can grab it when he wants to put the oil under pressure.

So now let’s see just how we work the thing.

OF COURSE we assume that there is oil in the main pipe-line, in the secondary pipe-line and in the outer chamber (low pressure chamber) of the reservoir. There isn’t oil in the center chamber (high pressure) because the plunger is down at the bottom. But all of this oil is under atmospheric pressure. In other words, not enough pressure to force the generator plunger up so that the revolving cam will strike it.

Okay, let’s go. We pull up the handle of the reservoir. In doing that we suck oil from the low pressure chamber into the high pressure chamber. Then we let go the handle and the spring tries to force the plunger down, and that action puts the oil under a pressure of 150 lbs. per square inch. Now the oil in the high pressure chamber and the oil in the secondary pipe-line is under pressure. The oil in the main pipe-line is not, because where the two pipe-lines join is a three-way valve. To get pressure in the main pipe-line we have got to open that three-way valve.

We do it this way. From the joy stick to that valve is a movable wire in a metal casing. (Something like the choke wire on your car.) On the joy stick that wire, called the Bowden control, is attached to a clamp you can press. Oftentimes it is attached to a thumb lever you push forward. But squeezing the clamp, or pushing the thumb lever, pulls the Bowden control wire and opens the three-way valve. Of course then the oil in the main line is put under pressure. And in being under pressure the plunger in the generator is forced up so that the revolving cam will strike it.

Alright, the cam strikes the plunger and forces it down. A pulsation, traveling at the rate of 4,000 ft. per second, starts back along the main pipeline. It reaches the point where the main pipe-line is joined to the secondary line. But because of the three-way valve it can’t shoot up the secondary line and hit against the reservoir plunger. So it carries right on along the main pipe-line and hits against the plunger in the trigger motor, and of course shoves it forward. And when the trigger motor plunger is forced forward, it of course trips the trigger of the lock and the gun is fired. Now, that pulsation after it has hit the trigger motor plunger naturally wants to bounce back along the main pipe-line. But we stop that by putting a check valve in the trigger motor. Then, of course, the pulsation can’t bounce back and interfere with pulsation coming forward.

We have yarned about this step by step. But of course you understand that these pulsations are traveling at the rate of 4,000 ft. per second, and things happen fast. And whenever the lock slides back again with its trigger cocked there are always pulsations to slap the trigger motor plunger forward and trip the trigger again.

IN CASE you’ve forgotten, all this is happening because we are still pressing the Bowden controls. Once we let go, the three-way valve closes and the main pipe-line goes back to ordinary pressure and the generator plunger sinks down where the revolving cam doesn’t hit it. To fire again we simply press the Bowden control and that opens the valve again. The 150 lbs. per square inch pressure is maintained for about ten bursts of any length. And then we have to pull up the handle again and renew the pressure. In order to get it clear in your minds about those pulsations, the oil being under pressure, a single pulsation is like a solid rod moving through the main pipe-line. And the number of pulsations is determined on how the cam shaft is geared to the prop boss. In other words, according to the speed of the revolving cam shaft.

And there you are.

No, we’re not. That young fledgling is checking on me again. “How about hitting the prop blades?” he asks.

Alright, it’s like this. The cam is set so that it strikes the generator plunger when the trailing edge of the prop blade (two-bladed prop) is one inch past the bore of the gun. In the case of a four-bladed prop the cam should be set when the center of the blade is right opposite the bore of the gun. That is, of course, assuming that the muzzle of the gun is four feet from the revolving prop blades. The nearer the gun is to the prop the nearer you set the cam to the trailing edge.

The Editor of this mag of yours has just looked over my shoulder and reminded me that I’m not writing a book, so I’d better quit.

And so, you fledglings, when these leading Hun getters trip triggers again, don’t let ’em kid you. They are just pressing the old Bowden control to open that three-way valve to put the main pipe-line under pressure so that the oil pulsation will trip the triggers. Can you beat it? . . . These sky birds are just a bunch of oil pumpers!
